IC200MDL744 GE Fanuc VersaMax AC Input Module

IC200MDL744 32-Point DC Output Module

GE Fanuc’s high-density output module delivers 32-point control for industrial systems. With dual isolated groups and negative logic, it handles complex automation tasks efficiently. Features hot-swap capability for zero downtime maintenance.

KEY BENEFITS

• Double isolation between groups (250V AC continuous)
• Two operating modes: 5V TTL or 12/24V DC
• 0.2ms ultra-fast response time
• Sinking outputs for negative logic systems
• LED status for every output point

TECHNICAL SPECIFICATIONS

• Brand: GE Fanuc
• Model: IC200MDL744 (Full suffix: IC200MDL74480808080)
• Output Type: 32-point sinking DC
• Voltage Range:
  • TTL Mode: 4.75-5.25VDC
  • Standard Mode: 10.2-30VDC
• Backplane Power: 140mA @ 5VDC
• Isolation: 1500V AC between groups
• Response: 0.2ms ON / 1.0ms OFF

INSTALLATION GUIDE

• Works with all Versamax PLC systems
• Requires NIU or CPU for operation
• Mount vertically for best thermal performance
• Use suppression diodes with motor loads

PACKAGE & SHIPPING

• 1x IC200MDL744 Module
• Mounting hardware included
• Warranty: 12 months
• Global shipping: FedEx | UPS | DHL
• No certificates included

FAQ

Q: Can I use both voltage modes together?
A: No, choose either TTL or standard mode for all outputs

Q: Is point isolation available?
A: No isolation between points – only between groups

Q: Maximum ambient temperature?
A: 60°C (140°F) with proper derating

Q: Compatible with AC loads?
A: DC negative logic only – not for AC
