IC200MDL743 Versatile Sinking Output Module: Triple Voltage Control
Product Overview
GE Fanuc’s IC200MDL743 handles 5V, 12V, and 24V DC loads with 16 sinking outputs. This negative logic module switches loads to DC ground. Features 0.2ms ON response and hot-swap installation. Perfect for industrial automation control.
Key Technical Specifications
- Brand: GE Fanuc
- Full Model: IC200MDL743-FFFF8080
- Output Type: Sinking (Negative Logic)
- Voltage Modes:
- 5V TTL (4.75-5.25V)
- 12/24V DC (10.2-30V)
- Points: 16 outputs in single group
- Speed: 0.2ms ON / 1.0ms OFF
- Backplane Power: 5V DC, 70mA
- Leakage Current: 0.5mA max at 30V
- Isolation: None between points/groups
Installation Made Simple
- Supports hot insertion during operation
- Use spring-style carriers for quick wiring
- Keep power/control wiring separate
- Connect to Versamax backplane securely
Package Contents
- IC200MDL743 output module
- Mounting hardware kit
- 12-month warranty
Global Shipping
Fast delivery via FedEx, UPS, or DHL. Real-time tracking included.
Common Questions
Q: Can I mix voltage types?
A: No – choose either 5V TTL or 12/24V mode for all points
Q: How many devices can one output drive?
A: Each point handles 0.5A max – check your device ratings
Q: Is fuse protection included?
A: No internal fuses – add external circuit protection
Q: Can I use this in safety systems?
A: Only for standard control – not safety-rated applications
