Product details
Digital Output – Bussed 24VDC – CC-PDOB01
Precision Industrial Control
This 24V digital output module from Emerson delivers reliable control for valves, relays, and process equipment. Features fuse-less short circuit protection and galvanic isolation for maximum uptime.
Key Specifications
| Brand/Model | Emerson CC-PDOB01 |
| Output Channels | 32 source-type |
| Voltage Range | 15-30 VDC |
| Current Capacity | 0.5A/channel 6A/module |
| Isolation | 1500 VAC RMS |
| Response Time | 10 ms max |
| Dimensions | 45x121x120 mm |
Advanced Safety Features
- Fuse-less short circuit protection
- Per-channel FAILOPT safe states
- Galvanic isolation (1500V)
- Continuous self-diagnostics
Flexible Output Modes
Configure each channel for: latching, pulsing, or PWM operation. Choose between internal or external 24V power sources.
Easy Installation
DIN-rail mountable. Weighs only 0.35 kg. Redundant models (CC-TDOB11) available for critical applications.
Compatibility
- Solenoid valves
- Interposing relays
- Process control equipment
- Works with Series C power systems
Package Contents
- CC-PDOB01 module
- Installation guide
- 12-month warranty
Global Shipping
Fast delivery via FedEx, UPS or DHL with tracking.
Automotive Assembly Success
Controlled 128 pneumatic valves across 4 production lines. Achieved 99.98% uptime with fuse-less protection.
FAQ
Q: What is FAILOPT?
A: Per-channel safety setting: hold last value or shed to safe state
Q: Redundancy options?
A: CC-TDOB11 model provides redundant outputs
Q: Maximum load per channel?
A: 0.5A continuous at 24VDC
