Honeywell CC-PDOD51 Series C Digital Output Module 24V 32-Channel

Honeywell CC-PDOD51 Series C Digital Output Module

The Honeywell CC-PDOD51 Series C Digital Output Module delivers reliable 24V DC switching for industrial control. It features 32 sink-type (open drain) outputs with galvanic isolation. Use it to operate solenoid valves, interposing relays, and other process equipment. The bussed design shares a common return, simplifying wiring. Choose internal or external field power for flexible installation.

Model Configuration Tree

• CC (Series C Platform)
  • PDOD51 (Digital Output Module)
    • P – Digital Output type
    • DOD – Digital Output Module
    • 5 – 24V DC, 32 channels, non-redundant
    • 1 – Coated for protection
• IOTA Options
  • CC-TDOD51 – Non-redundant, 9″ size
  • CC-TDOD61 – Redundant, 12″ size

Technical Specifications

• Brand: Honeywell
• Model: CC-PDOD51
• Type: Series C Digital Output Module
• Output Channels: 32
• Output Type: SINK (Open Drain)
• Load Voltage: 30 VDC maximum
• Load Current: 0.1 A per channel max
• Galvanic Isolation: 1000 VAC RMS system-to-field
• On-State Voltage: 0 VDC at 0.1A load
• Off-State Voltage: 24 VDC typical
• Off-State Leak Current: 100 µA max
• Turn-On/Off Time: 10 ms max
• Redundancy Gap: 0 ms switchover
• Protection: Conformal coated

Package Contents

• 1x CC-PDOD51 Digital Output Module
• 1x Installation guide
• 1x Warranty card
• IOTA ordered separately (CC-TDOD51 or CC-TDOD61)

Installation Basics

• Mount: Install on Series C IOTA base
• Wire: Connect field power (internal or external)
• Select power: Choose system or external 24V source
• Isolate: External power provides galvanic isolation
• Ground: All outputs share common return

Typical Applications

• Control solenoid valves in process lines
• Switch interposing relays for motor control
• Drive indicator lights and alarms
• Interface with PLC and DCS systems
• Industrial automation and manufacturing

Key Features

• 32 channels: High density in compact size
• Sink output: Open drain for flexible wiring
• Bussed design: Common return simplifies cabling
• Isolated: 1000V protection for system safety
• Coated: Conformal coating resists harsh environments
• Fast switching: 10ms response time

Redundancy Options

• Non-redundant: CC-TDOD51 IOTA, 9″ size
• Redundant: CC-TDOD61 IOTA, 12″ size
• Switchover: 0ms gap for seamless operation

Power Flexibility

• Use internal system power for simplicity
• Use external 24V for galvanic isolation
• Field power supplied by user
• Wiring option on IOTA selects source

Environmental & Compliance

• Operating temp: 0°C to +60°C
• Storage temp: -40°C to +85°C
• Humidity: 5% to 95% non-condensing
• Certifications: CE, UL, CSA
• RoHS compliant: Lead-free

Warranty & Support

• 12-month warranty against defects
• Technical support available
• Repair or replacement coverage

Shipping Information

• Couriers: FedEx, UPS, DHL
• Tracking: Provided upon dispatch
• Global: Fast worldwide delivery

Professional FAQ

• Q: What is the difference between CC-TDOD51 and CC-TDOD61 IOTAs?
• A: CC-TDOD51 is for non-redundant operation (9″ size). CC-TDOD61 supports redundancy (12″ size) with 0ms switchover.
• Q: Can I mix internal and external power on different channels?
• A: No. All 32 channels share a common return. Power source selection applies to all outputs together via IOTA wiring.
• Q: What does “bussed output” mean?
• A: All outputs share a common ground/return. This simplifies wiring when loads use the same power source.
• Purchase Guide: I need a module for a new Honeywell C300 controller. Is CC-PDOD51 compatible?
• A: Yes. The CC-PDOD51 is designed for Series C systems including C300. Use with appropriate IOTA (CC-TDOD51 or 61).
• Experience-based Q&A: Our plant has high vibration. Is the coating enough protection?
• A: The conformal coating protects against moisture and dust. For high vibration, ensure the IOTA is securely mounted. We recommend periodic checks of field wiring.
