Honeywell CC-PDIL01 Digital Input 24v Module

Honeywell CC-PDIL01 Digital Input Module

High-density industrial control for Experion Series C systems. 32-channel monitoring with ±0.1% accuracy and rugged design.

TECHNICAL SPECIFICATIONS

• Brand: Honeywell
• Model: CC-PDIL01
• Input Type: Dry contact
• Input Range: 0-30 VDC
• Impedance: >10 MΩ
• Accuracy: ±0.1% full scale
• Power: 24 VDC
• Dimensions: 263x58x28 mm
• Weight: 1 kg (2 kg shipping)

ENVIRONMENTAL RATINGS

• Operating Temp: 0°C to 60°C
• Storage Temp: -40°C to 85°C
• Humidity: 5-95% non-condensing
• Certifications: CE, RoHS

INSTALLATION GUIDE

• Mount in Experion Series C I/O rack
• Ensure proper 24VDC power supply
• Use shielded cables for noise reduction
• Maintain 50mm clearance for ventilation

COMPATIBILITY

• Experion Series C I/O system
• C300 Process Controller
• All dry contact field devices
• Honeywell Enterprise Integrator

PACKAGE CONTENTS

• 1x CC-PDIL01 Module
• Mounting hardware
• Note: No certificates included

SHIPPING & WARRANTY

• Global carriers: FedEx, UPS, DHL
• 12-month manufacturer warranty

FAQ

Q: What field devices are compatible?
A: All dry contact switches and sensors (0-30VDC)

Q: Can it handle AC inputs?
A: No, designed for 0-30VDC only

Q: Is DIN rail mounting supported?
A: Requires Experion Series C I/O rack

Q: What’s the maximum sampling rate?
A: 10ms per channel typical
