Honeywell CC-PCF901 Control Firewall Module | Series C FTE Distribution

Product Overview

Honeywell CC-PCF901 is a Control Firewall Module for Series C systems. It distributes FTE cables efficiently to multiple FIMs. The module mounts on CF9 I/O Termination Assembly (IOTA). It provides FTE distribution to in-cabinet network nodes like C300 Controllers. Compact design saves space in control panels. Low power consumption: 0.112A @ 24VDC.

Model Breakdown: CC-PCF901

• CC
  • Series: Honeywell Series C module
• PCF
  • Type: Control Firewall Module for FTE distribution
• 901
  • Model Number: Standard control firewall variant

Key Specifications

• Brand: Honeywell
• Model: CC-PCF901
• Product Type: Control Firewall Module
• Supply Rating: 0.112A @ 24VDC
• Mounting: CF9 I/O Termination Assembly (IOTA)
• Compatibility: C300 Controllers, Series C FIMs, in-cabinet nodes
• Function: Distributes FTE cables to multiple FIMs

Installation Guide

• Mounting Location: Install on CF9 IOTA inside control cabinet.
• Connection: Connect FTE cables from network to module.
• Power: Requires 24VDC supply at 0.112A.
• Wiring: Follow Honeywell termination assembly layout.

Maintenance Tips

• Inspection: Check cable connections annually for tightness.
• Cleaning: Keep module free of dust. Use dry compressed air.
• Firmware: Update via control system tools when needed.

Package Contents

• Includes: Honeywell CC-PCF901 module, installation guide.
• Warranty: 12 months against manufacturing defects.
• Mounting: CF9 IOTA sold separately.

Shipping Options

• Couriers: FedEx, UPS, DHL express worldwide.
• Packaging: Anti-static protective box.

System Applications

• FTE Distribution: Connects multiple FIMs to Fault Tolerant Ethernet.
• Cabinet Wiring: Reduces cable clutter inside control panels.
• Controller Network: Links C300 controllers to I/O modules.
• System Expansion: Adds FTE nodes without major rewiring.

Technical Benefits

• Space Saving: Mounts directly on IOTA, no extra DIN rail.
• Low Power: Only 0.112A at 24VDC, minimal heat output.
• Reliable: Passive distribution, no moving parts.
• Compatible: Works with all Series C FIMs and C300.

Expert FAQs

• Q: What does CC-PCF901 actually do in a system?A: It acts like a network splitter for FTE signals. One cable in, multiple FIMs connected. Keeps cabinet wiring organized.
• Q: Can I use this module without CF9 IOTA?A: No, it specifically mounts on CF9 Termination Assembly. The IOTA provides physical and electrical connections.
• Q: How many FIMs can one CC-PCF901 support?A: It distributes FTE to multiple Series C FIMs. Check Honeywell manual for exact count based on IOTA slots.
• Q: Is the module hot-swappable?A: Yes, Series C modules support hot swap. Remove and replace without powering down cabinet.
• Q: What is the 12-month warranty coverage?A: Covers defects in materials and workmanship. Does not cover physical damage or incorrect installation.
• Q: How fast is shipping for urgent projects?A: We ship via FedEx, UPS, or DHL. Express options deliver in 2-3 days. Tracking provided.
• Q: Does this module require configuration?A: No, it is passive. Plug and play. No software setup needed.
• Q: Can it be used with Experion PKS?A: Yes, it is part of Honeywell Experion Series C. Works seamlessly.

Selection Guide

• Choose CC-PCF901 if: You need to expand FTE network to multiple FIMs. Cabinet space is limited. You use Honeywell Series C system.
• Alternative: For different IOTA types, check CC-PCF901 variant compatibility. Always match with CF9 assembly.
• Power Tip: Calculate total 24VDC load. Module draws only 0.112A, leaving capacity for other devices.
• Installation Advice: Order CF9 IOTA together. Ensures correct fit and saves second shipment.
