Honeywell 900P24-0501 24VDC Power Supply | 5A Industrial PSU

Compact power: 900P24-0501

The Honeywell 900P24-0501 is a 24VDC Power Supply module. It delivers stable 5A continuous current. Designed for industrial control systems. It features screw terminals and wide voltage range. Reliable power for your Honeywell I/O. Tough, efficient, and easy to install.

Model structure explained

• 900P – Series: Honeywell 900 Power Supply family
  • 24 – Output: 24 VDC nominal voltage
    • 05 – Current: 5 Amps maximum continuous
      • 01 – Version: Standard model

Key specifications

• Input voltage range: 21 to 29 VDC – flexible for plant power.
• Output current: 5 Amps max continuous – steady and reliable.
• Inrush current: 30A for 3ms @ 29V DC – safe startup.
• Input rating: 72.5W / Output rating: 51W – efficient conversion.
• Fuse: Internal non-replaceable – protects against overload.
• Hold up time: 20 milliseconds @ 24V, full load – rides through dips.
• Wiring: Screw terminals, accepts 0.3 to 3.3 mm² (12-22 AWG).
• Temperature: T4 rated, 0°C to 51°C ambient.

Installation notes

• Mount on DIN rail or panel – compact size.
• Use copper conductors only – rated 60/75°C.
• Torque terminals to 0.8 Nm (7 lb-in).
• Leave 25mm space above/below for cooling.
• Do not block ventilation slots.

Five new FAQs

• Q1: What happens if the internal fuse blows?A1: The fuse is non-replaceable. If it blows, the unit must be replaced. We offer quick exchange service.
• Q2: Can I parallel two units for more current?A2: No, this model is not designed for parallel operation. Use a single 900P24-0501 for up to 5A load.
• Q3: What does T4 temperature rating mean?A3: T4 means maximum surface temperature ≤135°C. Safe for ordinary locations. Operating ambient is 0°C to 51°C.
• Q4: What wire gauge fits the screw terminals?A4: Terminals accept 12 to 22 AWG (0.3 to 3.3 mm²). Use stranded or solid copper wire. Strip length 7mm.
• Q5: How do you ship this power supply?A5: We ship via FedEx, UPS, and DHL. All units packed securely. Tracking provided. Express 2-4 days worldwide.

Selection tips

• Choose 900P24-0501 for 24V 5A needs in Honeywell systems.
• Great for powering I/O modules, controllers, and field devices.
• 12-month warranty covers defects. Extended options available.
• Check total load current – do not exceed 5A continuous.
• Keep ambient below 51°C for full life.
