Product Overview
Honeywell 900G32-0301 is a 24 VDC digital input module for industrial control systems.
It supports high-density signal monitoring with clear channel indication.
The module is built for stable operation in harsh environments.
- Thirty-two digital input channels
- Designed for 24 VDC field signals
- Clear LED status for each channel
- Fast response for real-time control
Core Technical Specifications
- Brand: Honeywell
- Model: 900G32-0301
- Series: 900 Digital I/O
- Module Type: Digital Input
- Input Count: 32 sinking inputs
Input Electrical Characteristics
- Input voltage range from 10 to 32 VDC
- Peak voltage up to 32 VDC
- ON state detected above 9.5 VDC
- OFF state detected below 3.5 VDC
Current and Impedance
- Input impedance around 6.9 kilo-ohms
- Typical current 1.7 mA at 12 VDC
- Typical current 3.5 mA at 24 VDC
- Minimum ON current of 1.0 mA
Response and Timing
- OFF to ON response within 5 milliseconds
- ON to OFF response within 5 milliseconds
- Fast reaction for safety and logic tasks
Isolation and Group Structure
- Inputs split into two groups
- Each group contains sixteen channels
- Separate common terminals per group
- Galvanic isolation up to 30 VDC
Status Indicators and Diagnostics
- Green LED for each active input
- Blinking green LED during scanning
- Red LED for module diagnostics
- Controller supports logic inversion
Configuration Breakdown
- 900G32
- Thirty-two channel digital input base
- -0301
- 24 VDC sinking input design
- Euro style 36-terminal block required
Environmental Limits
- Operating temperature from -40 to 70 °C
- Storage temperature up to 85 °C
- Suitable for outdoor and cabinet use
Typical Application Use
- Machine status monitoring
- Switch and sensor feedback
- Process automation systems
- Power and utility control panels
Warranty and Shipping
- Warranty: 12 months
- Courier Options: FedEx, UPS, DHL
- Fast global delivery supported
Professional FAQ
- When should I choose a 24 VDC input module
- Use it for standard industrial sensors and switches.
- Why are inputs divided into two groups
- It simplifies wiring and improves signal stability.
- How do LEDs help during maintenance
- They allow quick fault finding without tools.
- Is this module suitable for cold environments
- Yes. It supports operation down to -40 °C.
- How do I select the correct digital input module
- Check voltage level, channel count, and response time.
