Honeywell 900G03-0202 Digital Input Module 120/240VAC 16 Channel

Honeywell Digital Input Module 900G03-0202 Overview

• Brand: Honeywell
• Model: 900G03-0202
• Series: AC Digital Input
• Type: 16-Point 120/240 VAC Digital Input Module

• Functional Design Structure
  • Supports 16 sinking inputs.
  • Two groups of 8 channels.
  • Each group has its own common terminal.
  • External AC power drives input state.
  • Green LED per channel shows ON state.
  • Blinking green LED shows scan status.
  • Red LED shows diagnostic alarm.
  • Controller logic allows signal inversion.

Electrical Performance Tree

• Voltage Range
  • 80 VAC to 264 VAC operating range.
  • 264 VAC peak voltage.
• Frequency
  • 47 Hz to 63 Hz.
• Switching Levels
  • ON level: 75 VAC.
  • OFF level: 20 VAC.
• Input Characteristics
  • Impedance: 48K ohms nominal.
  • 1 mA at 120 VAC, 60 Hz.
  • 2 mA at 230 VAC, 50 Hz.
  • Minimum ON current: 0.3 mA.
  • Maximum OFF current: 0.2 mA.
• Response Time
  • OFF to ON: 4 ms + 1.5 cycles max.
  • ON to OFF: 4 ms + 2 cycles max.
• Isolation
  • 2 isolated groups.
  • 350 VAC max group isolation.

Configuration Breakdown

• 900G03-0202
  • 900G03
    • AC Digital Input platform
  • 02
    • 16-channel hardware layout
  • 02
    • Standard voltage version

Application Scope

• Motor starter feedback.
• AC limit switch monitoring.
• Power panel status input.
• Field device ON/OFF detection.
• Industrial safety signal reading.

Operational Advantages

• Wide AC voltage tolerance.
• Clear LED visual diagnosis.
• Fast switching response.
• Stable under high noise.
• Flexible logic inversion support.

Warranty & Logistics

• 12-month warranty from shipment date.
• Fast global shipping via FedEx, UPS, DHL.
• Strong anti-static protective packaging.

FAQ

• Can this module work with both 120VAC and 240VAC in one unit?
• Yes. It supports wide voltage range.
• Each group handles AC within limits.

• How to prevent false triggering in noisy panels?
• Keep wiring short.
• Separate from high power cables.
• Use proper grounding.

• Is it suitable for high-speed pulse signals?
• No. It is for AC state detection.
• Use high-speed input for pulse tasks.

• How do I choose between AC and DC input modules?
• Check field signal type first.
• Match voltage and frequency range.
• Confirm isolation needs.

• What support do you provide after purchase?
• 12-month product warranty.
• Technical support by email or WhatsApp.
• Fast shipment by FedEx, UPS, DHL.
