Honeywell 900ES1-0100 Serial Communication Module Modbus RTU RS232 RS485

Product Overview

The 900ES1-0100 Serial Communication Module connects industrial devices to a control system. It offers both RS232 and RS485 ports in one module. Use it to link smart sensors, drives, or third-party instruments. It supports Modbus and custom protocols. Built for extreme temperatures, it works reliably in harsh environments. This module simplifies serial integration with Experion PKS.

Model Breakdown

• 900 – Series Platform
  • ES1 – Communication Module Type
    • 0100 – Base Model Number

Key Features

• Dual Protocol Support: Modbus ASCII, Modbus RTU, and user defined protocols
• Multi-Port Design: 2 x RS232 ports (shared isolation) + 2 x RS485 ports (isolated from each other)
• High Isolation: 2000 VDC galvanic isolation for noise immunity
• Large Device Capacity: Connect up to 32 slaves per RS485 port
• Wide Temperature Range: Operates from -40°C to 70°C
• Flexible Baud Rate: 300 bps to 115200 bps, fully adjustable
• Diagnostic LEDs: Module status and channel activity indicators
• Experion Integration: Full diagnostic support with CPM

Technical Specifications

• Protocol Support:
  • Modbus ASCII Master
  • Modbus ASCII Slave
  • Modbus RTU Master
  • Modbus RTU Slave
  • User Defined Protocol
• Connector Types:
  • RS232: 9-Pin D-sub male (2 ports, shared isolator)
  • RS485: Terminal block (2 ports, isolated)
• Galvanic Isolation: 2000 VDC between ports and system
• Max Devices per RS485 Port: 32 slaves
• LED Indicators: Module status + per-channel communication
• Max Modules per CPM: 6
• Operating Temperature: -40 to 70°C
• Storage Temperature: -40 to 85°C
• Baud Rate: 300 to 115200 bps (adjustable)
• Flow Control: None, RTS-CTS, RTS
• Parity: None, Odd, Even
• Data Bits: 7, 8 (7 not supported on Modbus RTU)
• Stop Bits: 1, 2
• User Protocol Length: 532 bytes maximum
• Data Types Supported: USINT, UINT, UDINT, LINT, REAL, LREAL
• Experion Integration: Full diagnostic support

Installation Guidelines

• Mounting: Plugs into any Series-C I/O slot.
• Wiring RS485: Use twisted pair cable. Connect shield to ground.
• RS232 Connections: Standard DB9 pinout. Check baud rate match.
• Module Placement: Up to 6 modules per CPM controller.
• Configuration: Set protocol and parameters via Experion tools.

Diagnostic Capabilities

• LED Status: Quick visual check for module health.
• Per-Channel LEDs: Blink with traffic for easy troubleshooting.
• Experion Diagnostics: View communication errors and device status online.
• User Protocol Debug: Monitor raw data to verify custom protocol behavior.

Typical Applications

• Drive Control: Connect variable frequency drives via Modbus RTU.
• Third-Party Instruments: Interface with analyzers using custom protocols.
• Remote I/O: Gather data from Modbus slave devices across plant.
• Legacy Equipment: Bring older serial devices into Experion system.
• Multi-Drop Networks: Use RS485 to connect up to 32 devices per port.

Compatibility Information

• Controller: Works with C300 and other Series-C controllers.
• Software: Full integration with Experion PKS.
• Third-Party Devices: Supports any device using Modbus ASCII/RTU.
• Custom Protocols: Develop specific drivers using user defined protocol.

Frequently Asked Questions

• Q: Can I use both RS232 and RS485 ports at the same time?A: Yes. All four ports operate simultaneously. RS232 ports share one isolator. RS485 ports are isolated from each other.
• Q: How many total Modbus devices can I connect?A: Each RS485 port supports up to 32 slaves. With 2 ports, you can connect 64 devices. Plus you have 2 RS232 ports for point-to-point connections.
• Q: What is user defined protocol and when should I use it?A: User defined protocol lets you communicate with devices that do not use standard Modbus. You define the message structure up to 532 bytes. Use it for custom displays, barcode scanners, or specialized instruments.
• Q: What shipping methods are available and what is the warranty?A: We ship via FedEx, UPS, and DHL worldwide. The 900ES1-0100 comes with a 12-month warranty against defects.
• Q: Do you have any practical advice for first-time users?A: Start with Modbus RTU for most devices. Set baud rate and parity to match your field device. Use the diagnostic LEDs to confirm communication. If using custom protocol, test with a small data set first. Always terminate RS485 networks with 120 Ω resistors at both ends.

Package Contents

• 1x 900ES1-0100 Serial Communication Module
• 1x Product Documentation
• 12-month warranty period
• I/O termination accessories ordered separately

Ordering & Support Information

• Warranty: 12 months from delivery
• Shipping Partners: FedEx, UPS, DHL express
