Product Overview
Honeywell 900A16-0103 is a high level analog input module for industrial control systems.
It supports voltage and current signals with flexible point configuration.
The module processes all channels in parallel for fast response.
- Sixteen isolated analog input channels
- Voltage and current selectable per channel
- High accuracy factory calibration
- Designed for stable long-term operation
Core Technical Capabilities
- Brand: Honeywell
- Model: 900A16-0103
- Series: High Level Analog Input
- Module Type: Analog Input
- Channels: 16 isolated inputs
- Input Signals: Voltage and mA
Signal Performance Details
- Input impedance above 1 megaohm for voltage
- Input impedance 250 ohms for current signals
- Over-range support up to plus or minus 10 percent
- Resolution up to 15 bits
Accuracy and Stability
- Factory accuracy ±0.1 percent of full range
- Temperature drift within ±0.01 percent per °C
- Long-term stability of 0.1 percent per year
- Calibration data stored in non-volatile memory
Isolation and Noise Immunity
- 400 VDC point-to-point galvanic isolation
- 1000 VDC isolation to logic circuits
- Series noise rejection greater than 31 dB
- Common mode rejection above 90 dB
Conversion and Update Logic
- Dedicated A/D converter per module
- Analog conversion synchronized with CPU cycle
- Update rate of 100 milliseconds
- No scan time increase when adding modules
Status Indicators and Diagnostics
- Green LED shows active scanning
- Red LED indicates module or channel fault
- Monitors power supply and configuration status
- Detects calibration and hardware issues
Configuration Breakdown
- 900A16
- Sixteen channel analog input structure
- -0103
- High level voltage and current support
- Factory calibrated configuration
Typical Application Scenarios
- Process variable monitoring
- Power and utility control systems
- Manufacturing automation lines
- Oil, gas, and chemical plants
Warranty and Shipping
- Warranty: 12 months
- Shipping Methods: FedEx, UPS, DHL
- Fast international delivery available
Professional FAQ
- When should I choose a high level analog module
- Use it when signals are standard voltage or current.
- Does parallel processing improve system speed
- Yes. It avoids scan delays as systems grow.
- How often does calibration need adjustment
- Factory calibration remains stable for years.
- Is this module suitable for noisy plants
- Yes. Strong isolation and noise rejection help.
- How do I select between similar AI modules
- Check channel count, accuracy, and update speed.
