Product details
Honeywell 2MLR-DC42 Power Supply Module 24VDC Input
The Honeywell 2MLR-DC42 Power Supply Module converts 24VDC input to stable 5VDC output. It delivers 37.5W at 55°C with 65% efficiency. Features built-in fuses, RUN contact relay, and overcurrent protection. Compact design with LED status indicator. Ideal for industrial control systems requiring reliable DC power.
Model Configuration Tree
- 2MLR (Power Supply Series)
- DC42 (Specific Model)
- DC – DC input type
- 42 – 24VDC input / 5VDC output version
- DC42 (Specific Model)
Technical Specifications
- Brand: Honeywell
- Model: 2MLR-DC42
- Type: Power Supply Module
- Rated Input Voltage: 24 VDC
- Input Voltage Range: 19.2 ~ 28.8 VDC
- Inrush Current: 80A peak and lower
- Efficiency: 65% or higher
- Input Fuse: Built-in, non-user replaceable
- AC Fuse: 250V / 3.15A Time-lag UL approved
- DC Fuse: 125V / 10A Time-lag UL approved
- Instantaneous Interruption: Within 20 ms
- Output Voltage: 5 VDC (±2%)
- Output Current: 7.5A
- Output Power: 37.5W @ 55°C
- Over Current Protection: 9.0A ~ 17.0A
- RUN Contact Rating: 24VDC, 0.5A
- Min Switching Load: 5VDC, 1 mA
- Response Time: Off→On ≤10ms, On→Off ≤12ms
- Mechanical Life: 20+ million cycles
- Electrical Life: 100,000+ cycles
- Status Display: Green LED for normal output
- Cable Size: 0.75 ~ 2 mm²
- Clamped Terminal: RAV1.25-3.5, RAV2-3.5
- Dimensions: 55 x 95 x 110 mm
- Weight: 417g
Package Contents
- 1x 2MLR-DC42 Power Supply Module
- 1x User manual
- 1x Warranty card
- Terminal blocks included
Installation Basics
- Mount: Secure on DIN rail or panel
- Wire: Use 0.75-2mm² cable
- Connect input: 19.2-28.8 VDC supply
- Connect output: 5VDC to load
- RUN contact: Monitor module status
- Check LED: Green = normal operation
Key Features
- Wide input range: 19.2-28.8VDC flexible
- Dual fuses: AC and DC protection built-in
- RUN relay: Remote status monitoring
- Overcurrent protection: 9-17A trip range
- Fast response: 10ms max switching
- Compact: Space-saving 55mm width
- LED indicator: Quick visual check
Typical Applications
- Power Honeywell controllers and I/O
- Industrial automation panels
- Process control systems
- 24VDC to 5VDC conversion
- Backplane power supply
Protection Features
- Input fuses: Non-replaceable for safety
- Overcurrent: Automatic shutdown 9-17A
- Interruption tolerance: 20ms ride-through
- Thermal: Derated power at high temp
Environmental & Compliance
- Operating Temp: 0°C to +55°C
- Storage Temp: -40°C to +85°C
- Humidity: 5% to 95% non-condensing
- Certifications: CE, UL, RoHS
- Fuses: UL approved time-lag type
Warranty & Support
- 12-month warranty against defects
- Technical support available
- Repair or replacement coverage
Shipping Information
- Couriers: FedEx, UPS, DHL
- Tracking: Provided upon dispatch
- Global: Fast worldwide delivery
Professional FAQ
- Q: Why are there both AC and DC fuses in a DC-input module?
- A: The 2MLR-DC42 has dual protection. The AC fuse protects internal circuits if AC is mistakenly connected. The DC fuse protects normal DC operation.
- Q: Can I replace the internal fuses myself?
- A: No. Fuses are built-in and not user-replaceable. Return the unit for service if fuses blow. This ensures safety and proper repair.
- Q: What is the RUN contact used for?
- A: The RUN relay indicates normal output. Connect to a PLC or alarm to monitor power supply status remotely. Closes when output is normal.
- Purchase Guide: I need a 5VDC power supply for Honeywell I/O. Is 2MLR-DC42 compatible?
- A: Yes. The 2MLR-DC42 provides 5VDC at 7.5A, perfect for many Honeywell modules. Check your total current draw before ordering.
- Experience-based Q&A
: Our input voltage sometimes drops to 18V. Will this module work? - A: The input range is 19.2-28.8VDC. Below 19.2V, output may drop or shut down. Use a regulated 24VDC supply or voltage booster for stable operation.
