Product details
Key Capabilities
- The 2MLI-CPUH supports up to 6,144 installable I/O points for complex automation systems.
- Offers 3.5 MB program memory for large-scale applications.
- Supports IEC-standard programming: Ladder Diagram, SFC, and Structured Text.
- Includes 18 operator interfaces and 136 built-in functions with real number operations.
- Ensures deterministic scan operation with fixed and constant cycle options.
Technical Specifications
- Brand: Honeywell
- Model: 2MLI-CPUH
- Series: MasterLogic 200 Series
- Category: Programmable Logic Controller
- Max I/O Installable: 6,144 points
- Max I/O Memory Contact: 131,072 points
- Program Memory Capacity: 3.5 MB
- Symbolic Variable Area: 512 KB (max. 256 KB retainable)
- I Variable (I): 16 KB; O Variable (Q): 16 KB
- Direct Variable M: 256 KB (max. 128 KB retainable)
- Execution Speed: Basic instruction ~0.028 μs/step; MOVE instruction ~0.084 μs/step
- Operating Temperature: 0 to 55°C
- Control System: Scan synchronous batch processing & direct command I/O
- Operation System: Reiterative, fixed cycle, and constant scan modes
- Basic Function Block: 43 types; Dedicated Blocks: for special function modules & P2P communication
Installation Guide
- Mount on a standard 35 mm DIN rail inside a clean, dry control cabinet.
- Maintain ambient temperature within 0–55°C.
- Connect redundant or non-redundant I/O backplanes to appropriate terminals.
- Use shielded communication cables and proper grounding to prevent noise issues.
Packaging List
- One Honeywell CPU module 2MLI-CPUH with anti-static protection.
- Quick start guide and wiring diagram for installation.
- Mounting screws and label kit included.
- Global shipping available via FedEx, UPS, or DHL.
FAQ
- Q: What programming languages are supported?
A: Ladder Diagram, Sequential Function Chart (SFC), and Structured Text. - Q: How many I/O points does it support?
A: The 2MLI-CPUH supports up to 6,144 I/O points. - Q: What is the total program memory?
A: 3.5 MB of program memory for large, complex systems. - Q: Can the memory retain data after power loss?
A: Yes, retain options are available for symbolic and direct variable areas.
