Overview — Pyramid: Core Value First
The F 8628X provides reliable Profibus DP slave connectivity and efficient Ethernet programming for industrial automation systems. Designed for H41q and H51q systems, it enhances control performance and reduces programming time.
Key Features
- The F 8628X supports Profibus DP slave protocol for stable fieldbus communication in complex networks.
- Allows ELOP II programming via Ethernet from version 4.1 and above for faster CPU configuration.
- Compatible with CPUs F 8650X, F 8652X, F 8651X, and F 8653X in H41q/H51q control systems.
- Maintains compatibility with existing modules F8627 and F 8628 for legacy setups.
Technical Specifications
- Brand: HIMA
- Model: F 8628X
- Type: Profibus DP Slave Communication Module
- Form Factor: 19-inch rack module for H41q/H51q systems
- Dimensions: Height 3 × 44.45 mm, Width 4 × 5.08 mm
- Interfaces: 9-pin SUB-D and 100Base-T Ethernet (RJ45)
- Protocol: Profibus DP slave for deterministic network performance
- Programming: ELOP II Ethernet programming (from version 4.1)
- Compliance: IEC 61131-2, EN 61000-6, EN 50081-2, EN 50082-2, IEEE 802.3, EN 50170
Installation Guide
- Insert the F 8628X into the designated slot in a 19-inch H41q/H51q rack.
- Ensure firm mounting and proper grounding per standard control cabinet guidelines.
- Connect the 9-pin SUB-D port for Profibus and RJ45 port for Ethernet configuration.
- Use ELOP II version 4.1 or newer to establish Ethernet programming connection.
- Power on and check indicator LEDs for operational and network status.
Packaging List
- 1 × F 8628X Communication Module (factory-sealed)
- 1 × Quick-start installation guide
- 1 × Mounting accessory set (screws and SUB-D dust cap)
- 1 × Product identification card with serial and model number
Shipping & Handling
- Global express shipping available via FedEx, UPS, or DHL.
- Industrial-grade packaging ensures protection from vibration and ESD damage.
- Expedited delivery options available for urgent replacement needs.
FAQ
- Q: Which CPUs are compatible with the F 8628X?A: The module works with F 8650X, F 8652X, F 8651X, and F 8653X CPUs.
- Q: What ELOP II version supports Ethernet programming?A: Use ELOP II version 4.1 or later for Ethernet-based configuration.
- Q: Are older communication modules still supported?A: Yes, modules F8627 and F 8628 remain available for backward compatibility.
- Q: How should I connect the communication ports?A: Use the 9-pin SUB-D for Profibus and RJ45 for Ethernet setup.
