Product details
Overview
The HIMA F 8627X communication module delivers secure Ethernet communication for industrial safety systems and rapid diagnostics. Use this 100 Base-T RJ45 module for safeethernet, MODBUS-TCP, and OPC A&E integration in modern control networks.
Technical Specifications
- Manufacturer: HIMA
- Model: F 8627X — Part of the HIMA F86xx communication series.
- Interface: 100Base-T Ethernet (RJ45 connector), full duplex, auto-negotiation enabled.
- Protocols: Safeethernet, MODBUS-TCP slave, OPC A&E, and OPC DA via HIMA OPC Server.
- Operating Temperature: −40°C to +70°C ensuring stable performance in industrial environments.
- Standards Compliance: IEC 61131-2, EN 61000-6, EN 50081-2, EN 50082-2, IEEE 802.3, EN 50170.
- Dimensions: 19-inch rack mount module; 3 HU height (3 × 44.45 mm) and 4 WU width (4 × 5.08 mm).
- Safety Communication: Mono or redundant configuration for H41q and H51q systems.
Installation Guide
- Mount the module into a 19-inch rack compatible with H41q or H51q chassis.
- Connect the Ethernet cable to the RJ45 socket and verify the LED indicators before powering up.
- Use ELOP II programming tools over Ethernet to configure network settings and MODBUS mapping.
Package Contents
- 1 × F 8627X communication module
- 1 × Installation and user manual
- Mounting screws included (no certificates or warranty sheets inside)
- Shipping via FedEx, UPS, or DHL with tracking and insured delivery service.
Certifications & Standards
- Complies with IEC 61131-2 and EN 61000-6 EMC standards for reliable industrial performance.
- Meets EN 50081-2 and EN 50082-2 for emissions and immunity in harsh environments.
- Fully compatible with IEEE 802.3 and EN 50170 communication standards.
FAQ
- Question: What physical interfaces does the F 8627X module provide?
Answer: It includes one 100Base-T Ethernet RJ45 port supporting full duplex and auto-negotiation. - Question: Does the F 8627X support MODBUS-TCP and OPC A&E integration?
Answer: Yes, it supports both MODBUS-TCP slave mode and OPC A&E through the HIMA OPC server.
