GT2708-VTBA – Mitsubishi GOT2000 Programmable Touchscreen HMI
This HMI gives you clear control with an 8.4-inch color screen. It uses touch input and works in tough environments. The front is IP67F rated – resists dust and water. Easy to connect via Ethernet, USB, or serial ports.
Key Features
- 8.4-inch TFT color LCD – VGA resolution (640 x 480 pixels).
- 65,536 colors – sharp, clear visuals.
- Analog resistive touch – precise control, works with gloves.
- 57 MB ROM + 128 MB RAM – smooth operation and data storage.
- LED backlight – 60,000 hours life (non-replaceable).
- 32-level brightness – adjust for any light condition.
- Wide power range – 100-240 V AC, 50/60 Hz.
- IP67F front panel – dust-tight and water-resistant.
Technical Specifications
- Brand & Model
- Manufacturer: Mitsubishi Electric
- Series: GOT2000 Series
- Part Number: GT2708-VTBA
- Type: Programmable Touchscreen HMI
- Display System
- Screen Size: 8.4 inches
- Resolution: VGA (640 x 480 pixels)
- Technology: TFT color LCD
- Color Depth: 65,536 colors
- Brightness Adjustment: 32 levels
- Backlight: LED (non-replaceable)
- Life Expectancy: approx. 60,000 hours
- Touch Panel
- Type: Analog resistive film
- Precise touch response
- Memory
- ROM: 57 MB (storage)
- RAM: 128 MB (operation)
- Communication Interfaces
- Serial: RS-232, RS-422/485
- Ethernet: 1 channel
- USB: available ports for host/device
- Protection & Durability
- Front Panel: IP67F – dust-tight, water-resistant
- Inside Panel: IP2X – protected against solid objects
- Power Supply
- Input: 100-240 V AC, 50/60 Hz
- Power Consumption
- Max load: 15 W
- Backlight off: 10 W
- Physical
- Weight: 6.80 kg (15.00 lbs)
Simple Setup & Operation
- Panel-mount design – quick installation with brackets.
- Front USB port for easy project transfer.
- 32-level brightness – adapts to shop floor lighting.
- Non-replaceable LED backlight – no lamp changes needed.
- Built-in diagnostics reduce downtime.
- Runs on standard AC power – no external DC supply required.
Where to Use & Compatible Equipment
- Food & Beverage Plants – IP67F front handles washdowns.
- Automotive Assembly – monitor line status and quality data.
- Pharmaceutical Manufacturing – cleanroom compatible with easy cleaning.
- Packaging Machines – control speed, temperature, and alarms.
- Material Handling – conveyor control and diagnostics.
- Works with Mitsubishi PLCs (iQ-R, iQ-F, Q, L, FX) and third-party devices via Modbus.
Frequently Asked Questions
- Is this HMI suitable for wet or dusty areas?
- Yes. The front panel is IP67F rated – dust-tight and protected against water jets. Ideal for food and chemical plants.
- Can I use this HMI with a 24V DC system?
- No. This model runs on 100-240 V AC. If you need 24V DC, check other GOT2000 models like GT2708-VTBD.
- How do I transfer projects to this HMI?
- Use the USB port or Ethernet with GT Works3 software. Both methods are fast and reliable.
- What is the warranty and shipping policy?
- We provide 12-month warranty covering defects. Orders ship within 12-24 hours via FedEx, UPS, or DHL.
- Can I adjust the screen brightness for night shifts?
- Yes. There are 32 brightness levels. Operators can easily set the best level for any lighting condition.
Purchasing & Selection Guide
- Pick GT2708-VTBA when you need an AC-powered HMI with IP67F protection.
- Great for wet or dusty environments – front panel resists water and dust.
- Check your PLC communication: Ethernet, RS-232, or RS-422/485 are all supported.
- Memory (57 MB ROM) handles complex screens and data logging.
- We ship worldwide within 12-24 hours via FedEx, UPS, DHL.
- 12-month warranty included for peace of mind.
