Core Product Overview
The IS220YDOAS1A Discrete Output Pack from General Electric delivers robust performance for the Mark VIeS control system. This I/O pack acts as a vital electrical bridge between Ethernet networks and discrete output terminal boards. It ensures precise control and reliable operation in demanding industrial environments.
Key Technical Specifications
- Brand: General Electric
- Model: IS220YDOAS1A
- Series: Mark VIe & Mark VIeS Control System
- Output Channels: 14 buffered outputs
- Current Capacity: 400 mA maximum
- Temperature Range: -30 to +65 °C operating
- Ripple Specification: 280 mV pk
- Functional Type: YDOA Discrete Output
- Firmware Compatibility: V05.00 and later
- Shipping Weight: 0.8 pounds
Primary Functions and Capabilities
- Controls up to 12 relays for comprehensive output management
- Accepts terminal board-specific feedback for system monitoring
- Compatible with TRLYS1B, D, and F terminal board types
- Supports both simplex and TMR redundancy configurations
- Performs automatic self-diagnostic tests during power-up
Connection Interfaces
- Dual RJ-45 Ethernet connectors for network connectivity
- Three-pin power input for stable electrical supply
- DC-37 pin connector for terminal board integration
- Direct connection to associated terminal board connectors
- Seamless operation through either Ethernet port
Diagnostic Features
- Integrated LED indicators for real-time status monitoring
- Visual alerts for quick issue identification and resolution
- Comprehensive power-up testing of hardware components
- Memory verification including flash and RAM checking
- Ethernet port diagnostic capabilities
Installation Procedure
- Securely mount the terminal board in designated space
- Connect one YDOA pack for simplex operation
- Install three packs for TMR redundancy configurations
- Secure packs using threaded studs near Ethernet ports
- Adjust mounting bracket to prevent connector stress
- Connect Ethernet cables based on system requirements
- Apply power through side connector with soft-start feature
Configuration Requirements
- Utilize ToolboxST application for pack configuration
- ControlST Software Suite V06.01 or later versions
- Set operational parameters for specific applications
- Configure relay control and feedback mechanisms
- Enable diagnostic features as per operational needs
Packaging and Delivery
- Package includes IS220YDOAS1A I/O pack and documentation
- Total shipping weight: 0.8 pounds
- Global shipping via FedEx, UPS, and DHL carriers
- Secure packaging to ensure transit protection
- Quick dispatch from available stock
Frequently Asked Questions
- What is the maximum current rating?
The IS220YDOAS1A handles 400 mA maximum current per output.
- What temperature range does it support?
It operates reliably from -30 to +65 degrees Celsius.
- How many relays can it control?
This pack efficiently manages up to 12 relays simultaneously.
- What software is needed for configuration?
Use ToolboxST with ControlST Software Suite V06.01 or later.
- Is technical support available?
Contact us at sales@powergearx.com or +86 18030005825.
