General Electric IS220PDIAH1B Mark VIe I/O Pack Module

General Electric IS220PDIAH1B Mark VIe I/O Pack

The IS220PDIAH1B from General Electric is a compact and reliable I/O pack designed for the Mark VIe Speedtronic control system. Built for hazardous and non-hazardous zones, it delivers precise power distribution and monitoring performance across diverse industrial settings.

Author: Powergear X Automation

Key Highlights

• Certified for hazardous area use, ideal for demanding turbine environments.
• Nominal voltage of 24 VDC with a 28.6 VDC maximum rating.
• Maximum contact input voltage of 32 VDC ensures signal integrity.
• Operates between -30°C and +65°C ambient temperature range.
• Compatible with multiple GE terminal boards including IS200STCIH1A, IS200STCIH8A, IS200TBCIH2C, and IS400STCIH8A.

Technical Specifications

• Brand: General Electric
• Model: IS220PDIAH1B
• Product Type: PCB I/O Pack
• Series: Mark VIe Speedtronic
• Voltage Range: 18 to 32 VDC operating range
• Max Input Voltage: 32 VDC
• Ethernet Ports: Dual 10/100 Mbps for communication
• LED Indicators: Two ENET status lights
• Coating: Conformal PCB protective coating
• Assembly Type: Normal Assembly, Revision 1B
• Power Consumption: Less than 5 W
• Dimensions: Compact and lightweight module
• Certifications: UL listed for both hazardous and non-hazardous areas
• Operating Temperature: -30°C to +65°C
• Warranty: 12 months standard warranty
• Shipping: Worldwide via FedEx, UPS, DHL

Performance Features

• High signal accuracy with advanced filtering for industrial noise immunity.
• Supports flexible communication through dual Ethernet interfaces.
• Designed for reliability in turbine and automation systems.
• Durable PCB coating ensures extended lifespan under humidity and dust exposure.
• Easy integration with existing Mark VIe setups for simplified system maintenance.

Installation & Compatibility

• Mount directly with GE terminal boards for seamless system connection.
• Pairs effectively with IS200STCIH and IS400TBCIH board models.
• Ensure proper grounding and use shielded wiring to minimize interference.
• Follow GE’s Mark VIe manual for recommended wiring practices.

FAQ

• Q: What is the nominal voltage of the IS220PDIAH1B?
  A: It operates at 24 VDC nominal, with 28.6 VDC maximum.
• Q: Can this module work in hazardous locations?
  A: Yes, it is UL listed for both hazardous and non-hazardous zones.
• Q: What terminal boards are compatible with this I/O pack?
  A: It supports IS200STCIH1A, IS200TBCIH2C, and IS400STCIH8A boards.
• Q: What is the warranty coverage?
  A: Each unit includes a 12-month manufacturer warranty.
• Q: What shipping methods are available?
  A: FedEx, UPS, and DHL provide fast global delivery.
