General Electric IS200STCIH2AED Mark VI Terminal Board

General Electric IS200STCIH2AED Terminal Board

Powergear X Automation introduces the IS200STCIH2AED, a Simplex Contact Input Terminal Board from the Mark VI series by General Electric.
It offers 24 input channels, supports multiple voltage ranges, and ensures stable signal conditioning for turbine and process control applications.

Key Features

• Model: IS200STCIH2AED
• Brand: General Electric (GE)
• Series: Mark VI
• Product Type: Simplex Contact Input Terminal Board
• Country of Origin: United States (USA)
• Number of Channels: 24 dry contact voltage input channels
• Nominal Excitation Voltage: 24, 48, and 125 V DC
• Input Range: 16–32 V DC, 32–64 V DC, and 100–145 V DC
• Input Current: 2.5 mA (channels 1–21), 10 mA (channels 22–24)
• Response Time: 4 ms hardware filter
• Mounting: DIN-rail or flat cabinet mounting
• Connector Type: 37-pin D-type with a three-position female plug
• Material: Conformal coated PCB, A-rated revision
• Fault Detection: Voltage loss and input failure monitoring
• Dimensions: Compact board with dual circular mounting apertures
• Compatible Modules: PAIC I/O Pack, IS230SNCI, and IS230STCI

Technical Highlights

• Noise suppression filters protect against surge and high-frequency interference.
• Stable operation under wide excitation voltage ranges.
• Compact board design allows space-saving installation in dense control cabinets.
• Temperature operating range: –30°C to +65°C.
• Durable materials and quality PCB layout for long-term reliability.
• Quick signal processing converts input to digital for the controller.
• Supports fast communication via Ethernet through compatible I/O packs.
• Easy wiring using standard #18 AWG leads for all 24 contact points.

Package & Delivery

• 1 × IS200STCIH2AED Terminal Board
• 1 × DIN mounting insulator and metal carrier
• Packed with anti-static protection and documentation
• Warranty: 12 months from delivery date
• Worldwide shipping via FedEx, UPS, DHL with full tracking

Product Advantages

• Reliable 24-channel input for turbine and process monitoring.
• Flexible voltage compatibility ensures broad industrial usability.
• Compact, easy-to-install design reduces control cabinet space requirements.
• Noise-resistant input circuits for clean digital signals.
• Compatible with PAIC I/O packs for fast Ethernet-based communication.

FAQ

• Q: What power supply voltage does the IS200STCIH2AED support?
  A: It supports 24 V DC, 48 V DC, and 125 V DC excitation.
• Q: Can I use this board in redundant (dual) systems?
  A: No, the IS200STCIH2AED is designed for simplex systems only.
• Q: How many input channels can I connect?
  A: It provides 24 dry contact input channels with noise suppression.
• Q: What type of terminal block is compatible with this model?
  A: It uses a right-angle header supporting pluggable terminal blocks with 52 terminals.
• Q: Is field wiring complicated for setup?
  A: No, standard #18 AWG wires connect easily to the terminal strip.
