Product details
Overview
- Manufacturer: GE Vernova designs the IS420UCSCH1B for high-reliability industrial control applications.
- Product Family: Mark VIe Series — UCSC Gateway Stand-Alone Controller tailored for turbine and BoP control tasks.
Key Technical Specifications
- Brand & Model: Manufacturer GE Vernova builds the IS420UCSCH1B Quad Core Controller in the Mark VIe product series for industrial use.
- Memory: 4 GB DDR3-1333 SDRAM with ECC ensures stable deterministic runtime performance.
- CPU: 1.2 GHz quad-core processor with QNX Neutrino hypervisor supports multitasking and control stability.
- Ethernet: Six Ethernet ports — five on the front panel and one bottom port for Predix cloud connectivity.
- NVSRAM: Stores 3067 program variables, 64 totalizers, and 338 forces for secure nonvolatile data retention.
- Redundancy: Supports simplex, dual, and TMR redundancy via dedicated IONet ports with precision synchronization.
- Environment Range: Operating from -40°C to +70°C; storage from -40°C to +85°C for extended durability.
- Dimensions & Weight: 8.03 x 5.99 x 2.17 inches; approximately 1,327 g with mounting.
- Service Ports: Includes USB and RJ45 COM ports for setup, UEFI redirection, and ToolboxST access.
- Virtual Network: Hypervisor-managed virtual network links the EFA and Mark VIe control VMs securely.
Installation Guidelines
- Install the Mark VIe cabinet in a temperature-controlled environment on a flat, level surface.
- Ensure proper convection cooling and seal conduits to maintain airflow temperature limits.
- Mount vertically with proper cable routing to prevent stress and ensure easy maintenance.
Cable Separation & Routing
- Maintain proper separation between signal and power cables to minimize electrical interference.
- Follow level rules and use shielded twisted pair cables for Ethernet where necessary.
- Consult GE Mark VIe manuals for conduit, grounding, and wiring best practices.
Diagnostics & Reliability
- Built-in software and hardware limit checking detects abnormal conditions for early alerts.
- ECC memory and NVSRAM preserve data and enable safe recovery after power interruptions.
- ToolboxST software provides full diagnostic and monitoring visibility during commissioning.
Packaging List
- 1 × IS420UCSCH1B Controller Module
- DIN-rail brackets, protective packaging, and quick start card
- Ethernet dust caps, USB flash drives for ToolboxST setup
- GEH-6855 printed installation checklist for reference
- Shipping by FedEx, UPS, or DHL — global delivery available
Supported Interfaces & Ports
- 3 IONet R/S/T ports for I/O communication with IEEE 1588 synchronization
- ENET1 for EGD/UDH links to ToolboxST PCs, HMIs, and GE PACSystems products
- ENET2 for secondary UDH communication, Modbus TCP, and OPC UA services
- Dedicated Predix port for Embedded Field Agent and secure cloud connectivity
FAQ
- Q: What redundancy configurations are supported by the IS420UCSCH1B?
A: It supports simplex, dual, and TMR redundancy configured via IONet and ToolboxST. - Q: How can the Embedded Field Agent connect securely to Predix?
A: Use a managed switch for network segmentation while linking EFA through the bottom Predix port. - Q: How do I restore or update the controller firmware?
A: Insert the ToolboxST USB flash drive and follow UEFI serial redirection steps using the COM port.
Contact & Sales
- For inquiries: sales@powergearx.com or +86 18030005825 (WhatsApp)
- Powergear X provides pre-sales consultation, configuration support, and fast international shipping.
