GE Nexus 369B1868G0008 AO Module | Analog Output Terminal Board Product

Overview

The GE Nexus 369B1868G0008 analog module provides accurate analog output for industrial automation tasks.

Powergear X Automation creates this description to highlight core functions and practical installation guidance.

Key Features

• The GE Nexus 369B1868G0008 supports 0–10V, ±10V, and 4–20mA output modes.
• The design uses isolated circuits and stable D/A conversion to deliver clean analog signals.
• The module processes data locally and supports fast control cycles.
• The unit works with servo valves, VFDs, and other analog-driven equipment.

Technical Specifications

• Brand: GE Automation, Series: Nexus, Model: GE Nexus 369B1868G0008.
• Output range: 0–10V, -10–+10V, and 4–20mA.
• Resolution: 16-bit for smooth control response.
• Linearity: 0.1% FS for reliable signal accuracy.
• Noise immunity: Stable output in heavy industrial EMI areas.
• Frequency response: Fast enough for real-time control loops.
• Temperature range: -20°C to +60°C.
• Isolation: Optical isolation prevents ground interference.
• Update rate: High refresh speed suits motion and closed-loop work.

Installation Guide

• Insert the module into a Nexus rack and ensure proper alignment.
• Use twisted shielded cable and ground the shield at one point.
• Separate signal wiring from high-current motor lines.
• Set output mode in system configuration before field wiring.
• Verify output with a calibrated meter before commissioning.

Packaging List

• One GE Nexus 369B1868G0008 module in protective packaging.
• One quick start leaflet with wiring and pinout details.
• Mounting screws and required hardware.
• One label with model and serial information.

Shipping & Contact

• Ships via FedEx, UPS, and DHL.
• Email: sales@powergearx.com
• WhatsApp: +86 18030005825

FAQ

• Q: How do users choose voltage or current mode?
• A: Configure the output mode in system I/O setup before wiring.
• Q: What cable works best for long distances?
• A: Use shielded twisted pair to reduce noise pickup.
• Q: Can the module support motion control?
• A: Yes, the fast output refresh suits motion systems.
• Q: How should users check signal drift?
• A: Inspect grounding, routing, and remeasure outputs under load.
