GE IS210BAPAH1A Analog Processor Module – Mark VI Control

GE IS210BAPAH1A Analog Processor Module | Mark VI Series

The IS210BAPAH1A by General Electric is a high-performance Analog Processor Module
from the Mark VI Series. It manages and regulates analog signals in GE Speedtronic gas turbine systems,
ensuring precision, stability, and safety in turbine operations.

Product Highlights

• Brand: General Electric (GE)
• Model: IS210BAPAH1A
• Series: Mark VI Speedtronic
• Function: Analog Processor Module for gas and steam turbines
• Country of Manufacture: United States (USA)
• Input Voltage: 125 V DC
• Output Voltage: 24 V DC
• Operating Temperature: -30°C to +65°C
• Mounting Type: DIN-rail for secure installation
• Dimensions: 23.5 cm (H) × 10.8 cm (W)
• PCB Coating: Conformal Coating for protection and long life
• Weight: Approx. 1.2 kg
• Availability: In Stock | Repair Time: 3–5 Days
• Warranty: 12 months
• Shipping via FedEx, UPS, and DHL worldwide

Key Functions

• Interfaces with sensors to collect analog data such as temperature, pressure, and speed.
• Conditions analog signals through built-in amplifiers, filters, and converters.
• Generates control signals to manage fuel flow, combustion, and turbine speed.
• Processes feedback signals for precise performance adjustment.
• Detects faults early using built-in diagnostic and monitoring logic.
• Integrates seamlessly with digital controllers and communication systems.

Performance Features

• Supports analog-to-digital signal integration for efficient turbine control.
• Compact black housing allows airflow for reliable cooling and continuous operation.
• Front panel includes LED indicators for power, signal, and fault monitoring.
• Pairs with SAMB terminal board for acoustic monitoring input in frame 6/7/9 gas turbines.
• Engineered for durability with reinforced coating against dust and humidity.
• Designed for industrial-grade turbine environments requiring 24/7 uptime.

Installation Overview

• Mount on standard DIN-rail using the integrated rear flanges.
• Connect signal inputs and outputs using appropriate terminal boards.
• Ensure adequate ventilation to maintain optimal temperature conditions.
• Follow installation manual GEH-6721 for safety and wiring details.

Technical Data Summary

• Functional Acronym: BAPA
• Functional Revision: 1A
• Model Type: Safety I/O Pack
• Nominal Output Current: 2.5 A
• Response Time: < 5 ms
• Power Consumption: 20 W (typical)
• Environmental Protection: IP20 rated housing

FAQ

• Q: What is the primary use of the IS210BAPAH1A?
  It processes and regulates analog sensor signals in gas and steam turbine systems.
• Q: Can this module be installed in both Mark VI and Mark VIe systems?
  Yes, it is compatible with both GE Mark VI and Mark VIe control architectures.
• Q: How is the module cooled during continuous operation?
  It features vented housing with airflow channels to prevent overheating.
• Q: What kind of coating protects the PCB inside the module?
  A conformal coating shields the circuit board from dust, humidity, and corrosion.
• Q: How do I order or request technical assistance?
  Contact us at sales@powergearx.com or message via WhatsApp +86 18030005825.

Contact Information

• Email: sales@powergearx.com
• WhatsApp: +86 18030005825

Partners & References

• Original Source: https://www.powergearx.com/ for more GE Mark VI product data.
• Partner: Ubest Automation Limited for automation systems and module sourcing.
• Copyright © 2025 Powergear X Automation Limited. All rights reserved.
