GE IS200VAICH1C Analog I/O Board for Mark VI Turbine Systems

High-Performance Analog I/O Board for Turbine Control

The IS200VAICH1C by General Electric is a versatile analog I/O board designed for Mark VI turbine control systems. This board handles 20 analog inputs and 4 analog outputs with precision. It supports both simplex and triple modular redundant configurations for reliable operation.

Key Specifications

• Manufacturer: General Electric (GE)
• Model: IS200VAICH1C (Revision C)
• Series: Mark VI Turbine Control
• Channels: 24 total (20 AI + 4 AO)
• Input Types: Voltage, 4-20 mA
• Output Types: 4-20 mA, 0-200 mA configurable
• Sampling Rate: 200 Hz for stall detection
• Load Resistance: Up to 500Ω (#18 wire)
• Operating Temp: -30°C to 65°C
• Warranty: 12 Months
• Shipping: FedEx, UPS, DHL

LED Status Indicators

• GREEN (RUN): Flashing indicates normal operation
• RED (FAIL): Solid indicates critical failure
• ORANGE (STATUS): Steady indicates diagnostic alarm

Compatibility Information

• Works with TBAIH1B terminal boards and earlier versions
• Compatible with all DTAI terminal board revisions
• Requires TBAIH1C or later for higher load resistance
• Integrates with STAI terminal boards

Installation Steps

• Power down the VME processor rack completely
• Slide the board into the designated slot carefully
• Engage top and bottom levers to secure edge connectors
• Tighten captive screws on the front panel firmly
• Verify all LED indicators show proper status

Frequently Asked Questions

• What makes the IS200VAICH1C suitable for turbine control?

• It offers triple modular redundancy and compressor stall detection for maximum reliability in critical turbine applications.

• How many input channels does the board support?

• The board handles 20 analog inputs and 4 analog outputs for comprehensive monitoring and control.

• Can this board operate in extreme temperatures?

• Yes, it operates reliably in temperatures ranging from -30°C to 65°C for harsh industrial environments.

• What diagnostic features are included?

• It features hardware limit checking, system limit monitoring, and real-time fault detection with LED indicators.

• Is the IS200VAICH1C compatible with older systems?

• Yes, it works with multiple generations of terminal boards including TBAIH1B and DTAI versions.
