Product details
GE Fanuc IC200BEM002: Versamax Profibus DP Communication Module
High-performance network interface for Versamax PLC systems. 12 Mbaud Profibus DP connectivity with DIN rail mounting. Ideal for industrial automation networks.
Core Specifications
- Brand: GE Fanuc
- Model: IC200BEM002
- Series: Versamax
- Data Rate: 9.6 Kbaud to 12 Mbaud
- Network Size: 32 stations (125 with repeaters)
- I/O Capacity: 384 bytes data transfer
- Connector: 9-pin D-sub
Technical Features
- Protocol: Profibus DP
- Impedance: 135-165 ohms
- Power Consumption: 460 mA @ 5VDC
- Data Processing: 244 bytes in/out simultaneously
- Firmware: Ver 1.00 (flash upgradable)
- Wire Gauge: >0.64 mm
Installation & Indicators
- Mounting: DIN rail compatible
- LED Indicators: Power status + COM activity
- Installation Tip: Align connectors in unlocked position
- Enclosure: Open design (indoor use only)
- Environment: Keep away from heat sources
Certifications & Support
- CE compliant
- RoHS compliant
- Warranty: 12 months
- Global Shipping: FedEx, UPS, DHL
FAQ
Q: What’s the maximum network distance?
A: Depends on data rate – up to 1200m at 9.6 Kbaud
Q: Can I upgrade the firmware?
A: Yes, flash memory upgradable via serial connection
Q: Is this suitable for outdoor use?
A: No, open enclosure design for indoor only
Q: What cable type is required?
A: Profibus DP certified cable (>0.64mm gauge)
