GE Fanuc IC200MDL331 – Heavy-Duty AC Output Module
High-Current Control Solution
8 isolated outputs with 2A/channel capacity. Handles 120V AC loads with 20A inrush current. Built-in MOV/snubber protection. Made for industrial automation control systems.
Power Specifications
- Output Channels: 8 fully isolated
- Voltage Range: 85-132V AC
- Current Capacity: 2A per point (continuous)
- Inrush Handling: 20A (1 cycle)
- Response Time: ½ cycle (8.3ms)
- Voltage Drop: <2V at full load
- Leakage Current: <2mA maximum
- Backplane Power: 85mA @ 5V DC
Protection Features
- Individual MOV surge protection
- Snubber circuits per output
- 1500V AC optical isolation
- 250V AC continuous isolation
- Short-circuit protection
Installation Guide
- External Power: 85-132V AC required
- Wiring: Terminal block connections
- Load Types: Relays, solenoids, lamps
- Max Wire Size: 12 AWG
- Mounting: Versamax carriers (all types)
System Compatibility
- Emerson Versamax systems
- GE RX3i/RX7i controllers
- Legacy GE Fanuc PLCs
- All Versamax I/O carriers
Package & Support
- Factory-sealed module
- 12-month performance warranty
- Global shipping: FedEx/UPS/DHL
- Express delivery: 2-3 business days
Expert Answers
Q: Minimum load requirement?
A: 10mA per channel to maintain operation
Q: Output status indication?
A: 8 channel LEDs + 1 system OK LED
Q: Surge protection rating?
A: MOV circuits handle 6kV transient spikes
Q: Supports DC loads?
A: No – designed for AC only (47-63Hz)
Q: Environmental limits?
A: -40°C to +85°C operating temperature
