GE Fanuc IC200DBI001: Smart Network Control Hub
Powerful DeviceNet Connectivity
The IC200DBI001 links up to 64 devices without routers. Perfect for factory automation and control systems.
Technical Specifications
Brand: GE Fanuc
Model: IC200DBI001
Network Power:
– 64 nodes max per network
– Data rates: 125/250/500 Kbaud
– 128 bytes I/O data capacity
Electrical:
– Power: 160mA @5V, 10mA @3.3V
– Connector: 5-pin open style
– Signals: V+, CAN_H, Shield, CAN_L, V0
Environment:
– Temp: 0°C to 60°C (32°F to 140°F)
– Certifications: CE, cULus
– Class 1 Div 2 rated
Easy Installation
- Rear latch for secure mounting
- LEDs show power, network status
- Passive network termination
Warranty & Shipping
12-month quality warranty. Fast worldwide delivery:
- FedEx (2-3 days)
- UPS (3-5 days)
- DHL (1-4 days)
Smart Features
- Supports multiple protocols
- Polling data transfer
- Fault LED for quick diagnostics
Expert Answers
Q: Maximum cable length?
A: 500m at 125Kbaud, 250m at 250Kbaud, 100m at 500Kbaud
Q: Included termination resistor?
A: Yes – 120Ω resistor built-in
Q: Works with non-GE devices?
A: Yes – any DeviceNet compatible equipment
Q: LED colors meaning?
A> Green=OK, Red=Fault, Yellow=Network activity
Q: Replacement part number?
A: IC200DBI001 is the current version
