Emerson IC200ALG320 – High-Speed 4-Channel Current Output Module
Product Highlights
New IC200ALG320 output module delivers ultra-fast 0.3ms response for control systems. Features four precision 4-20mA outputs with 12-bit accuracy. Includes fault protection and ships with 12-month warranty.
Key Specifications
- Output Channels: 4 independent
- Output Range: 4-20mA precision
- Resolution: 4µA steps (12-bit)
- Speed: 0.3ms update time
- Power Requirements:
- 18-30VDC standard
- 9.6-15VDC alternative
- Accuracy: ±0.3% typical
- Isolation: 250VAC continuous
Critical Features
- Fault response modes: Hold last value or default to 4mA
- Dual LED status indicators (FLD PWR + OK)
- Single-ended wiring configuration
- Built-in diagnostics for power loss
- Compact single-slot design
Wiring & Setup
- Power Connection: Requires external DC power supply
- Output Load: Supports valves, VFDs, positioners
- Jumper Configuration: Sets fault response behavior
- Max Current Draw: 240mA @ 24VDC
Safety & Diagnostics
- 1500VAC isolation (1-minute rating)
- Automatic power loss detection
- Field power monitoring (FLD PWR LED)
- Backplane status indicator (OK LED)
Package Contents
- IC200ALG320 module
- Configuration jumpers
- 12-month manufacturer warranty
Shipping Options
Worldwide delivery via FedEx, UPS, DHL. Ships within 24 hours.
FAQ
- Q: Minimum output current change?
A: 4μA precision steps - Q: Can I use different power supplies?
A: Yes, 18-30VDC or 9.6-15VDC options - Q: What happens during power failure?
A: Configurable – hold last value or drop to 4mA - Q: Suitable for safety systems?
A> Basic protection only – add safety relays for critical applications
