GE Fanuc | VersaMax Analog Input Module IC200ALG264

Emerson IC200ALG264 – High-Precision 15-Channel Current Input Module

Product Snapshot

New IC200ALG264 analog module with 15 current inputs. Features ultra-precise 15-bit resolution for industrial monitoring. Ships factory-sealed with 12-month warranty.

Key Features

• 15 input channels in one group
• Super-sensitive detection: 0.5µA per count
• Dual-range operation: 4-20mA or 0-20mA
• Open wire detection capability
• Single-slot module design

Technical Performance

• Resolution: 15-bit (32,768 counts)
• Accuracy:
  • ±0.3% at 0-25°C
  • ±1.0% at 0-60°C
• Speed: 7.5ms update time
• Input Impedance: 100Ω
• Isolation: 250VAC continuous
• Power Usage: 100mA @5VDC

Module Setup

• Jumper Configuration:
  • No jumper = 4-20mA mode
  • Jumper installed = 0-20mA mode
• Single-ended wiring
• No external power needed
• LED status indicator (OK light)

Diagnostics & Safety

• Open wire detection (4-20mA mode)
• Power loss detection
• 1500VAC isolation (1 minute)
• Error reporting to control systems

Package Details

• IC200ALG264 module
• Configuration jumpers
• 12-month quality warranty

Global Shipping

Fast delivery via FedEx, UPS, DHL. Tracking included.

Common Questions

• Q: Minimum current change detected?
  A: 0.5μA in 4-20mA mode
• Q: Can I mix 4-20mA and 0-20mA signals?
  A: No – all channels same mode
• Q: How to check for wiring problems?
  A: Module detects open wires automatically
• Q: Suitable for hazardous areas?
  A: Basic protection only – check local regulations
