GE Fanuc Series 90-30 Voltage Output Module IC693MDL916

IC693MDL916 Series 90-30 Relay Output Module

Main Technical Details

• Output Points: 16 Form A (Normally Open) relays
• Channel Isolation: Each output is individually isolated
• Voltage Range: 5 to 125 VDC / 5 to 250 VAC
• Max Output Current: 4 Amps per point
• Min Output Current: 10 milliamps
• Switching Frequency: Up to 20 operations per minute
• Field to Backplane Isolation: 250 VAC continuous
• Power Draw: 300 mA at 5 VDC
• Module Width: Single-slot
• Status Display: One LED per output

Installation Guide

The IC693MDL916 fits in a GE Fanuc Series 90-30 PLC rack or PACSystems RX3i. It uses one slot. Connect using compatible terminal blocks such as IC694TBBx32 or IC694TBSx32. The DIP switch on the back sets how outputs behave when the CPU stops. This setting must match the software configuration.

Working Conditions

• Continuous AC Isolation: 250 Volts
• Peak Isolation: 1550 Volts for 1 minute
• Relay Load Types: AC (up to 250 V), DC (up to 125 V)
• Pilot Duty Rating: 2 Amps

Package Contents

• IC693MDL916 Output Module
• Quick Setup Guide
• Mounting Screws
