GE Fanuc Series 90-30 Voltage Output Module IC693MDL652

GE Fanuc IC693MDL652 48VDC Discrete Input Module | Series 90-30 | 16-Point Simulation Input

Product Overview

The GE Fanuc IC693MDL652 is a discrete input module made for Series 90-30 PLC systems. It supports simulation of up to 16 input points, allowing users to test input responses without external field wiring. This module is ideal for development, training, and diagnostics in industrial systems.

Core Technical Specifications

• Input Voltage Range: 0 to 60 VDC
• Trigger Voltage: 34 to 60 VDC
• Input Current: 4.2 mA (standard), 7.5 mA (at rated voltage)
• Number of Input Points: 16
• Response Time: 1 ms ON / 1 ms OFF
• Connector Type: Terminal block (20 screws included)

Power Requirements

• Internal Power Draw: 80 mA at 5 VDC
• Isolated Power Draw: 125 mA at 24 VDC

Input Logic and Signal Handling

• Logic Type: Positive and Negative
• On-State Voltage: Minimum 15 VDC
• Off-State Voltage: Maximum 6 VDC
• Input Simulation: 16 two-position switches for testing inputs

Warranty and Shipping

• 12-month warranty
• Ships via FedEx, UPS, or DHL
• Secure anti-static packaging for global delivery
