GE Fanuc IC693MDL645 24VDC Input Module | 16 Points | Series 90-30

Product Overview

The GE Fanuc IC693MDL645 is a DC input module for the Series 90-30 PLC system. It supports both positive and negative logic. It has 16 input points with LED status indicators. Each input reads a signal and stores it in the PLC’s input memory table. It is ideal for use with pushbuttons, sensors, limit switches, and other discrete devices.

Key Technical Details

• Rated Voltage: 24 V DC
• Input Voltage Range: 0 to 30 V DC
• Trigger Voltage: 11.5 to 30 V DC (On), 0 to 5 V DC (Off)
• Input Current: 7 mA typical
• On-State Current: 3.2 mA min
• Off-State Current: 1.1 mA max
• Response Time: 7 ms on/off
• Isolation: 1500 V between field and logic side

Module Features

• Input Points: 16 (1 group with common)
• Logic Type: Positive / Negative
• Status Indicators: 16 LEDs (1 per point)
• Module Width: Single slot
• Mounting: Series 90-30 5-slot or 10-slot baseplate
• Connector: Terminal block with 20 screws (included)

Electrical Requirements

• Power from 5 V Bus: 80 mA
• Power from 24 V Isolated Bus: 125 mA

Application Examples

• Packaging line pushbutton control
• Factory floor limit switch input
• Sensor signal feedback in robotic systems
• Manual override inputs for motor starters

Installation Tips

• Use in a dry, dust-free panel
• Ensure proper grounding and wiring
• Follow terminal block labeling
• Secure module using baseplate latch

Warranty and Shipping

• 12-month limited warranty
• Ships by DHL, FedEx, or UPS
• Secure anti-static packaging
