GE Fanuc Series 90-30 Voltage Output Module IC693MDL640

GE Fanuc IC693MDL640 24V DC Discrete Input Module | Series 90-30

Overview

The IC693MDL640 is a 24V DC input module made for GE Fanuc Series 90-30 PLCs. It uses positive logic and has 16 input points with one common group. It connects sensors or other devices to the PLC for signal reading.

Main Technical Specs

• Logic Type: Positive
• Rated Voltage: 24 V DC
• Input Voltage Range: 0 to 30 V DC
• Input Points: 16
• Isolation: 1500 V RMS (field to logic)
• Input Current: 7.5 mA typical at 24 V DC
• On-State Current: 4 mA minimum
• Power Usage: 5 to 120 mA
• Response Time: 7 ms (typical)
• Status Indicators: 16 LEDs (1 per input)
• Operating Temp: 0 to 60°C
• Humidity: 5% to 95% non-condensing

Installation Guide

• Install into any Series 90-30 baseplate slot
• Connect user-supplied 24 V DC to input devices
• Wire all inputs with common group logic
• Check LED lights to verify input status

Shipping and Warranty

• 12-month warranty included
• Ships with protective wrap and static-safe bag
• Fast worldwide shipping via FedEx, UPS, or DHL
