GE Fanuc Series 90-30 Voltage Output Module IC693MDL632

GE Fanuc IC693MDL632 125V DC Input Module | Series 90-30

Overview

The IC693MDL632 is a 125V DC input module from the GE Fanuc Series 90-30 PLC line. It has 8 input points that work with both positive and negative logic. Each input has an LED that shows its ON or OFF state.

Key Technical Specs

• Voltage Type: DC
• Rated Voltage: 125 V DC
• Input Voltage Range: 0 to 150 V DC
• Inputs: 8 points, in 2 isolated groups
• Logic Type: Positive or Negative
• ON-State Voltage: 90 to 150 V DC
• OFF-State Voltage: 0 to 30 V DC
• ON-State Current: 3.1 mA (typical)
• Field to Logic Isolation: 1500 V
• Group to Group Isolation: 500 V
• Status Display: Top-row LEDs show input status
• Module Access: Hinged front door with label insert
• Operating Temperature: 0°C to 60°C

Installation Guide

• Fits into a Series 90-30 baseplate
• Secure with latches on each side
• Power the field devices externally with 125V DC
• Each group has its own common (not tied together)
• Use label on hinged door for wire help

Compatibility

• Works with GE Fanuc Series 90-30 PLC systems
• Use with 5-slot or 10-slot I/O baseplates
• Not made for newer PACSystems RX3i

Industrial Problems It Solves

• Need to read high-voltage DC signals? Handles up to 150V DC input
• Confused by mixed logic systems? Works with both logic types
• Need fast status checks? LEDs show point status clearly
• Worried about safety? High isolation helps prevent damage
