GE Fanuc Series 90-30 Power Supply Module IC693PWR330

GE Fanuc IC693PWR330 High-Capacity PLC Power Supply

Enhanced Power for Industrial Automation

30W high-capacity power module for GE Fanuc Series 90-30 PLC racks. Features universal AC/DC input and boosted 5VDC output for larger systems. Provides critical backplane power with industrial-grade protection. Note: This discontinued product remains available for legacy system support.

Technical Specifications

• Brand: GE Fanuc
• Model: IC693PWR330 (Series 90-30)
• Input:
  • 85-264VAC or 100-300VDC
• Outputs:
  • 5VDC @ 30W (Backplane power)
  • 24VDC Isolated @ 20W
  • 24VDC Relay @ 15W
• Protection: Overvoltage (6.4-7V), Overcurrent (7A max)
• Holdup Time: 20ms minimum
• Certifications: UL, CE

Key Advantages

• 30W 5VDC output for larger PLC racks
• Universal power input (85-264VAC/100-300VDC)
• RS-485 programming port (9-pin sub-D)
• Enhanced holdup time (20ms) for power stability
•  Status LEDs: PWR, OK, RUN, BATT

Installation Guidelines

• Must install in leftmost rack slot
• 6 terminal connections (polarity-sensitive for DC)
•  AC wiring: L1/L2/Ground to top 3 terminals
•  DC wiring: +/- to top 2 terminals
•  Minimum 20ms power holdup during interruptions

System Compatibility

Designed exclusively for GE Fanuc Series 90-30 PLC systems:

• • Larger PLC racks requiring 30W backplane power
• • Relay output modules (24VDC @15W)
• • 24VDC input modules
• • HHP handheld programmers

Certifications & Compliance

UL Listed | CE Marked | Industrial Safety Standards

Package Contents

• 1x IC693PWR330 Power Supply Module
• Installation manual
• 12-month replacement warranty

Global Shipping

FedEx | UPS | DHL | Priority international options

Frequently Asked Questions

Q: Why does it require the leftmost slot?
A: This position provides direct backplane power distribution.

Q: Can it power entire PLC systems alone?
A: Designed for primary power in single-slot configurations.

Q: Is the RS-485 port programmable?
A: Yes, connects HHP programmers and workstations.
