GE Fanuc Series 90-30 I/O Bus Expansion Cables IC693CBL313

GE Fanuc IC693CBL313 Long-Range Expansion Cable

25-foot shielded cable for daisy-chaining Series 90-30 PLC racks. Discontinued – final units in stock.

Cable Specifications

• Brand: GE Fanuc (Emerson)
• Model: IC693CBL313 (Full Suffix)
• Length: 25 feet (7.6 meters)
• Wire Gauge: 28 AWG shielded copper
• Weight: 2.0 lbs (0.9 kg)
• Hot-Swap: Not supported

Connection Details

• End A: Single 25-pin male connector
• End B: Dual-head (male + female)
• Max Expansion: 50 feet total
• Max Remote: 700 feet total
• Shielding: Continuous EMI protection

Compatibility

For Series 90-30 systems:

• All CPU models (331-364)
• Expansion baseplates
• Remote I/O racks
• Required: Terminator plug IC693ACC307

Installation Steps

1. Connect male end to CPU baseplate
2. Attach dual-end male to first expansion rack
3. Use dual-end female for next cable or terminator
4. Never exceed total distance limits

Warranty & Shipping

• Coverage: 12-month replacement
• Shipping: FedEx, UPS, DHL (2-3 days)
• Includes: Cable + installation sheet

FAQ

Q: How many cables per system?
A: Up to 7 cables with CPU 350-364.

Q: Can I connect remote racks?
A: Yes, supports remote racks up to 700 feet.

Q: Is termination required?
A: Yes, use IC693ACC307 at last connection.

Q: Replacement for shorter cables?
A: No, use only where 25-foot runs needed.
