GE Fanuc RX3i Pacsystem IC694MDL930 Output Module

GE Fanuc IC694MDL930 Relay Output Module for RX3i Systems

Product Overview

The IC694MDL930 is an 8-point relay output module. It works with RX3i control systems. Each output is isolated and uses a dry contact. You can use it for both AC and DC loads. It is good for lights, motors, and solenoids. It works well in many industrial jobs.

Key Technical Specs

• Module Type: Relay Output
• Total Outputs: 8 (each one is isolated)
• Contact Style: Form A (Normally Open)
• Voltage Range: 5–30 VDC or 5–250 VAC
• Nominal Voltage: 24 VDC or 120/240 VAC
• Max Current: 4 Amps per output (resistive load)
• Pilot Duty Current: 2 Amps
• Min Load: 10 mA
• Inrush Current: 5 Amps max
• Backplane Load: 6 mA (5V); 70 mA (24V)
• Response Time: 10 ms (on/off)
• Isolation: 250 VAC (continuous), 1500 VAC (1 minute)
• Relay Life: Up to 1 million cycles

Installation Tips

• Use in RX3i system racks
• Works in local or remote setups
• Fits Series 90-30 racks
• No built-in protection; add fuses if needed

System Support

• Works with RX3i CPUs
• Also supports Series 90-30 platforms

What’s in the Box

• 1 IC694MDL930 Relay Module
• Quick Start Guide (Digital)
• No certificate included

Warranty and Shipping

• 12-month warranty
• Ships with FedEx, UPS, or DHL
• Packed with care for safety

Problem Solved

• Less wiring needed in control panels
• Works with both AC and DC power
• Easy swap for older GE modules
• Protects gear by using relay contacts
