GE Fanuc RX3i Pacsystem IC694MDL635 Output Module

GE Fanuc IC694MDL635 RX3i 125V DC 16-Point Input Module

Product Summary

The IC694MDL635 is a high-voltage DC input module for the RX3i PACSystem. It has 16 input points in one group.

Main Technical Specs

• Part Number: IC694MDL635
• Brand: GE Fanuc
• Series: RX3i PACSystem
• Rated Voltage: 125V DC (positive or negative logic)
• Input Voltage Range: 0 to 150V DC
• Input Current: 1.97 mA at rated voltage
• Input Points: 16 (single group)
• Power Use: 80 mA (5V bus), 31.5 mA (user power)

Input Characteristics

• ON Voltage: 90 to 150V DC
• OFF Voltage: 0 to 30V DC
• ON Current: 1.41 mA
• OFF Current: 0.46 mA
• ON Response Time: 8 ms (typical)
• OFF Response Time: 8 ms (typical)

Environmental Ratings

• Work Temp: 0 to 60°C (32 to 140°F)
• Storage Temp: -40 to 85°C (-40 to 185°F)
• Humidity: 5% to 95% non-condensing
• Shock: 15G for 11 ms
• Vibration: 10 to 57 Hz, 0.0524 mm peak; 57 to 500 Hz, 1.0G max

Package Includes

• 1 x IC694MDL635 Module
• No certificate included
• 12-month warranty

Shipping Options

• FedEx
• UPS
• DHL

Why Choose This Module

• Reliable for 125V DC signal detection
• Works in harsh industrial environments
• Compact 16-point input setup
• Backed by GE’s proven quality
