GE Emerson RX3i 240V AC Output Module – IC694MDL330
Description
High-power output module for PACSystems RX3i. Features 8 isolated AC outputs (2 groups of 4) with 2A switching capacity. Designed for heavy-duty industrial loads with built-in surge protection.
Technical Specifications
| Brand | GE Fanuc / Emerson |
| Model | IC694MDL330 (Full suffix: IC694MDL330) |
| Output Points | 8 points (2 groups × 4) |
| Rated Voltage | 120-240V AC |
| Current per Point | 2A continuous |
| Frequency | 50/60 Hz ±3Hz |
| Operating Temp | 0°C to 60°C (32°F to 140°F) |
| Storage Temp | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 5% to 95% non-condensing |
Installation Guide
- Single-slot mounting in RX3i backplane
- Connect separate AC power to each group common
- Do not use DC power supplies
- Allow 50mm clearance for heat dissipation
Compatibility
- PACSystems RX3i controllers
- AC loads: contactors, solenoids, motor starters
- Not compatible with DC loads
Packaging Includes
- 1x IC694MDL330 Output Module
- Installation manual
- No certificates included
Shipping & Warranty
- Global express: FedEx / UPS / DHL
- 12-month manufacturer warranty
FAQ
Q: Can I use one power supply for both groups?
A: Yes, but separate phases recommended for critical loads
Q: What protection is included?
A: Each group has 5A fuse + RC snubbers
Q: Maximum load per channel?
A: 2A resistive, 0.5A inductive (AC-1)
Module Comparison
| Feature | IC694MDL330 | IC694MDL250 | IC694MDL260 |
| Type | Output | Input | Input |
| Voltage | 120-240V AC | 12-24V AC/DC | 24V DC |
| Points | 8 | 16 | 16 |
| Current | 2A/point | 4-8mA | 9mA |
| Isolation | Group (2×4) | Single group | Channel |
| Surge Protection | RC snubbers | None | None |
