GE Fanuc RX3i IC693ALG221 Analog Current Input Module

GE Fanuc IC693ALG221 4-Channel Analog Current Input Module

Technical Specifications

• Input Range: 4-20 mA, 0-20 mA
• Channels: 4 single-ended inputs
• Resolution: 12-bit; 4 µA at 4-20 mA, 5 µA at 0-20 mA
• Accuracy: ±0.1% full scale + 0.1% reading
• Input Impedance: 250 ohms
• Update Rate: 2 ms (all channels)
• Input Filter Response: 325 Hz
• Isolation: 1500 Vrms between field and logic
• Power: 25 mA at 5 VDC, 100 mA at 24 VDC (isolated)
• Operating Temperature: -10 to 60 °C

Installation Guide

• Fits any Series 90-30 I/O rack slot
• Use twisted, shielded cables to reduce noise
• Connect to isolated +24 V DC power supply
• Configure input range via jumpers on terminal block
• Ensure power supply can handle module load

Compatibility

• Works with all Series 90-30 PLC systems
• Supports hardware range selection per channel pairs
• Compatible with many industrial analog sensors

Applications & Solutions

• Industrial process monitoring with precise current measurement
• Energy management with accurate analog input data
• Signal conversion for legacy sensors to digital control
• Noise reduction in harsh industrial environments

Package Contents

• 1 x IC693ALG221 Analog Current Input Module
• 12-month warranty included
• No certificates included

Shipping Information

• Ships via FedEx, UPS, DHL
• Fast delivery with tracking
