GE Fanuc Motion Mate Control Module IC693PCM300

IC693PCM300 Programmable Coprocessor Module

Boost your Series 90-30 PLC with this dual-mode processor. Runs as Comm Coprocessor (CCM) or ASCII/BASIC Module (ABM).

Dual-Mode Power

• Switch between CCM or ABM functions
• 2 configurable serial ports
• Runs MegaBasic applications
• Lithium battery backup for memory

Technical Specifications

• Brand: GE Fanuc
• Model: IC693PCM300
• Serial Ports: 2 (RS-232/RS-485)
• Memory Backup: Lithium battery
• Status LEDs: 3 (OK + 2 user-programmable)
• Hot-Swap: Not supported
• Backplane Power: 5VDC

Diagnostic LEDs

• OK LED: Solid = operational, Flashing = booting, Off = fault
• USER 1/USER 2: Programmable status indicators

Compatibility

• GE Series 90-30 PLC systems
• IC693CBL304 expansion cable
• Standard serial devices (printers, HMIs)

Package & Warranty

• IC693PCM300 module
• 12-month performance warranty
• Global shipping: FedEx/UPS/DHL

FAQs

• Q: Battery replacement procedure?
  A: Replace with power on within 30 seconds
• Q: Max cable length for serial ports?
  A: 50 feet (15m) at 115.2k baud
• Q: Can I use both modes simultaneously?
  A: No – configure as either CCM or ABM
• Q: Program storage capacity?
  A> Holds 10+ custom MegaBasic programs
• Q: Compatible with Series 90-70?
  A> Only with IC693CBL304 adapter cable
