GE Fanuc Motion Mate Control Module IC693DSM302

IC693DSM302 Dual-Axis Motion Controller

Add precision motion control to your GE Series 90-30 PLC. This discontinued GE Fanuc module drives 2 axes with 5ms response time.

Core Capabilities

• Controls 2 servo motors simultaneously
• Direct support for GE digital servos + 3rd-party analogs
• Built-in RS-232 port for firmware updates
• Stores 10 programs + 40 subroutines

Technical Specifications

• Brand: GE Fanuc
• Model: IC693DSM302 (Series 90-30)
• Response Time: < 5 milliseconds
• Position Range: ±8,388,607 user units
• Max Velocity: 8,388,607 units/sec
• Max Acceleration: 134,217,727 units/sec²
• Backplane Power: 5VDC (450mA typical)
• Operating Temp: 0°C to 60°C (32°F to 140°F)

Environmental Ratings

• Operating Temp: 0°C to 60°C
• Storage Temp: -40°C to 85°C
• Protection Class: Not specified (industrial use)
• Vibration/Shock: Standard PLC tolerance

Diagnostics & Maintenance

• Real-time axis position monitoring
• Error code feedback via PLC
• Firmware updates via RS-232 port
• No routine calibration needed

Compatibility

• GE Series 90-30 PLC racks
• GE digital servo motors
• SL Series analog servos
• Third-party analog servos

Package & Warranty

• IC693DSM302 controller module
• 12-month performance warranty
• Global shipping: FedEx/UPS/DHL

FAQs

• Q: Max servo power supported?
  A: Depends on drive units; controller handles signals only
• Q: Can I daisy-chain multiple units?
  A: Yes, up to 4 controllers per PLC rack
• Q: Replaceable without PLC shutdown?
  A: No – requires full system power-off
• Q: Position feedback resolution?
  A: 24-bit precision (±8 million counts)
• Q: Works with stepper motors?
  A: Only with compatible servo drives
