GE Fanuc IC697PWR720 Power Supply Adapter | Series 90-70 Module

Power Supply Adapter Module

The IC697PWR720 supports Series 90-70 racks with stable power and clean distribution. It fits one slot and feeds the full backplane. Author: Powergear X Automation

Main Operating Features

• The module sends 18A at 5VDC, 2A at 12VDC, and 1A at -12VDC.
• It mounts in the power supply slot of any Series 90-70 rack.
• It works with GE Fanuc Emerson power units or a 3rd-party supply.
• The design follows the VME Standard C.1.
• The module includes a clear Logic Power LED for fast status checks.

Technical Highlights

• Brand: GE Fanuc Emerson
• Model: IC697PWR720
• Series: Series 90-70
• Type: Power Supply Adapter (PSA)
• Weight: 1.25 lbs (0.57 kg)
• Voltage Output: 5, 12, and -12 VDC
• Nominal Output: 5.07V / 12V / -12V
• Voltage Window: +5.02–5.12V, +11.58–12.42V, –11.4–12.6V
• Current Limits: 18A / 2A / 1A
• 5V Bus Draw: 50 mA
• Rack Support: IC697 and WME racks
• Dual Rack: Supported with IC697CBL700
• Slot Width: Single slot
• Lifecycle: Discontinued, widely supported

Power and System Behavior

• The module drives heavy rack loads with stable output levels.
• The design handles long runtime needs in industrial systems.
• The external supply must meet a 5.05 ms hold-up time.
• The supply must also send a TTL Power OK signal.
• The module keeps rack logic clean during power drops.

Installation Notes

• Insert it in the power supply slot only.
• Wire the external source before energizing the rack.
• Use cable IC697CBL700 for dual-rack links.
• Check rack airflow and leave space for cooling.

Packing List

• One IC697PWR720 PSA module
• Safe anti-static packing
• Ships with FedEx, UPS, or DHL
• Includes 12-month warranty

Product Strengths

• Strong 18A load support for large racks
• Fast install process with clean slot layout
• Stable voltage window under heavy load
• Supports complex dual-rack builds
• Wide compatibility across Series 90-70 systems

FAQ

• Q: How do I confirm the rack takes this module?
  A: Check if the rack supports Series 90-70 power slots.
• Q: What is the most common install mistake?
  A: Users forget to add the hold-up requirement for the external supply.
• Q: When should I use the IC697CBL700 cable?
  A: Use it only when linking a second rack.
• Q: Can this module run full load for long hours?
  A: Yes, if the supply stays within rated limits.
• Q: What LED state shows stable logic power?
  A: The Logic Power light stays on without blinking.
