GE Fanuc IC694MDL734 RX3i PACSystem AC Output Module

GE Fanuc IC694MDL734 125V DC Output Module for RX3i PLC System

Product Overview

The IC694MDL734 is a DC output module from the GE Fanuc RX3i PACSystem series. It supports both positive and negative logic. This module has 6 isolated outputs that can be used with many industrial DC loads. Each output has a status LED.

Main Technical Specifications

• Model: IC694MDL734
• Type: Output Module
• Outputs: 6 (isolated)
• Rated Voltage: 125V DC
• Voltage Range: 10.8 to 150V DC
• Output Current: 1 Amp per point
• Inrush Current: 7 Amps (100 ms, 2% duty)
• Logic: Positive and Negative
• Fuses: Not included

Installation Guide

• Can be installed in any RX3i rack slot
• Simple plug-in method
• Must be installed by trained personnel
• Connect to proper DC loads before power-up

Compatibility

• Works with RX3i PACSystem PLC racks
• Suitable for DC solenoids, alarms, indicators
• Supports industrial loads up to 150V DC

Status and Monitoring

• 6 LEDs show output status
• Each LED lights up when the point is active

Package Includes

• 1 x IC694MDL734 Output Module
• User Label
• Warranty: 12 Months
