GE Fanuc IC694MDL660 RX3i PACSystem AC Output Module

GE Fanuc IC694MDL660 32-Point Input Module RX3i PACSystem

Product Overview

The IC694MDL660 is a 32-point discrete input module from the GE Fanuc RX3i PACSystem. It supports both positive and negative logic and includes four isolated groups of eight input channels. It is ideal for industrial control where fast, accurate input detection is needed.

Key Technical Specifications

• Model: IC694MDL660
• Brand: GE Fanuc (formerly GE Intelligent Platforms, now Emerson Automation)
• Series: RX3i PACSystem
• Type: Discrete input module
• Number of Inputs: 32 (4 groups of 8)
• Logic: Positive / Negative
• Rated Voltage: 24 VDC
• Current Draw: 195 mA @ 5VDC; 224 mA @ 24VDC
• Response Time: 0.5 ms to 100 ms (selectable)
• Input Filter Times: 0.5, 1.0, 2.0, 5, 10, 50, 100 ms
• Isolation: 250 VAC continuous, 1500 VAC for 1 min
• Inrush Current: 4.78 A for 10 ms

Installation Guidelines

• Fits in any I/O slot in an RX3i rack
• Use terminal blocks: IC694TBB032 (box) or IC694TBS032 (spring)
• Maximum cable length: 30 meters
• Not compatible with Series 90-30 CPUs

Industrial Use Cases

• Factory automation systems
• Equipment with high-speed input needs
• Environments with electrical noise requiring filter tuning
• Sensor-driven process control

Package Contents

• 1 x IC694MDL660 Input Module
• No certificates included
• 12-month warranty included
