GE Fanuc IC694MDL646 RX3i PACSystem AC Output Module

GE Fanuc IC694MDL646 RX3i 24V DC 16-Point Input Module

Product Overview

The IC694MDL646 is a 24V DC input module designed for the RX3i PACSystem. It supports both positive and negative logic. This module includes 16 input points and can be used in any RX3i I/O slot. It is ideal for basic signal input tasks in automated systems.

Main Technical Specifications

• Part Number: IC694MDL646
• Brand: GE Fanuc
• Series: RX3i PACSystem
• Rated Voltage: 24V DC
• Input Logic: Positive or Negative
• Input Voltage Range: 0 to 30V DC
• Input Current: 7 mA (typical)
• Input Points: 16
• Power Use: 80 mA (5V bus), 125 mA (24V supply)

Input Signal Characteristics

• ON Voltage: 11.5 to 30V DC
• OFF Voltage: 0 to 5V DC
• ON Current: Min 3.2 mA
• OFF Current: Max 1.1 mA
• ON Response Time: 1 ms
• OFF Response Time: 1 ms

Package Contents

• 1 x IC694MDL646 Input Module
• Excludes certification
• Warranty: 12 months

Shipping Methods

• FedEx
• UPS
• DHL

Key Benefits and Solutions

• Fast signal detection with 1 ms timing
• Low power use supports energy-efficient setups
• Clear LED feedback aids in fault tracing
• Works well in tough factory conditions
