GE Fanuc IC693MDL653 Series 90-30 AC Output Module

GE Fanuc IC693MDL653 32-Point Discrete Input Module | 24VDC | Series 90-30

Product Overview

The GE Fanuc IC693MDL653 is a high-density discrete input module made for the Series 90-30 PLC system. It features 32 input points and supports both positive and negative logic signals. With its compact design and multiple groups, it is ideal for space-saving installations in large automation systems.

Key Technical Specifications

• Input Voltage Range: 19.2 to 28.8 VDC
• Nominal Voltage: 24 VDC
• Trigger Voltage: Minimum 15 VDC
• Input Current: 7.5 mA at rated voltage
• Response Time: 2 ms ON / 2 ms OFF
• Input Points: 32 total (4 groups of 8 points)
• Commons: 2 per group

Power and Isolation

• Internal Power Usage: 5 mA from 5V backplane (all inputs on)
• Isolation: 1500 VAC between field and logic sides
• On-State Current: Minimum 4.5 mA
• Off-State Current: Maximum 2 mA

Warranty and Shipping

• 12-month warranty
• Ships worldwide via FedEx, UPS, or DHL
• Secure and anti-static packaging included
