GE Fanuc IC693MDL641 Series 90-30 AC Output Module

GE Fanuc IC693MDL641 24V DC Negative Logic Input Module | 16 Channels | Series 90-30

Product Overview

The IC693MDL641 is a 16-point DC input module from GE Fanuc. It is part of the Series 90-30 PLC family. This module uses negative logic and connects sensors or switches to the PLC for real-time monitoring.

Key Technical Specifications

• Logic Type: Negative
• Rated Voltage: 24 V DC
• Input Voltage Range: -30 to 30 V DC
• Input Points: 16
• On-State Voltage: 15 to 30 V DC
• Off-State Voltage: -30 to 5 V DC
• On-State Current: 4 mA minimum
• Off-State Current: 1.5 mA maximum
• Input Current: Typical 7.5 mA
• Isolation: 1500 V RMS between field and logic side
• Power Usage: 5 V internal, 120 V from user supply
• Response Time: 7 ms (typical)
• Indicators: 16 input status LEDs
• Operating Temperature: 0 to 60°C
• Humidity Range: 5% to 95% non-condensing

Installation Guidelines

• Install in a clean, dry PLC cabinet
• Mount to any Series 90-30 baseplate slot
• Wire inputs according to negative logic polarity
• Ensure user-supplied power is within rated range

Solves Real-World Problems

• Limited input space?
• Offers 16 inputs in one compact module
• Need quick status check?
• Each channel has a clear LED indicator
• Handling sensitive signals?
• 1500 V isolation protects your PLC
• Challenging install areas?
• Works reliably in 0–60°C, high-humidity setups
