GE Fanuc IC693MDL310 RX3i PACSystem AC Output Module

GE Fanuc IC693MDL310 120V AC Output Module with 12 Points

Product Summary

The IC693MDL310 is a 120V AC output module from the GE Fanuc Series 90-30 PLC family. It has 12 output points divided into 2 isolated groups of 6. Each point supports up to 0.5 Amps current and is protected by internal fusing and noise suppression.

Technical Specifications

• Output Points: 12
• Group Division: 2 groups of 6 points each
• Output Voltage Range: 85 to 132 V AC
• Nominal Voltage: 120 V AC
• Output Current per Point: 0.5 A
• Inrush Current: 5 A for 1 cycle
• Leakage Current: 3 mA max at 120 V AC
• Frequency: 50/60 Hz
• Fuse: 3 A per group (non-replaceable)
• LED Indicators: 6 for status display

Advantages and Pain Points Solved

• RC snubbers reduce noise from power lines
• Isolated output groups enhance signal safety
• Allows mix of loads using separate power phases
• LEDs simplify output status checks

Package Contents

• 1 x GE Fanuc IC693MDL310 output module
• Terminal block not included
• No certificate enclosed

Warranty

• 12-month warranty from shipping date

Shipping Methods

• FedEx
• UPS
• DHL
