GE Fanuc IC693CPU311 Series 90-30 Embedded CPU Module

Overview, Features, and Technical Specifications

The IC693CPU311 is a 5-slot baseplate with an integrated 80188 CPU designed for the Series 90-30 Programmable Logic Controller (PLC) platform. Originally manufactured by GE Fanuc (now part of Emerson Automation), this baseplate provides a compact and efficient solution for industrial automation systems. With a clock speed of 10 MHz and a Boolean execution time of 18 ms per 1K logic, it is capable of managing various I/O points and supporting SNP slave and SNP-X slave communication protocols.

Technical Specifications:

• Brand: GE Fanuc (Emerson Automation)
• Model: IC693CPU311
• Processor: 80188, 16-bit architecture
• Processor Speed: 10 MHz
• Program Memory: 6 Kbytes of user program memory
• I/O Points:
  • Discrete Inputs: 160 points
  • Discrete Outputs: 160 points
  • Analog Inputs: 64 words
  • Analog Outputs: 32 words
• Boolean Execution Speed: 18 ms per 1K logic
• Clock Speed: 10 MHz
• Timers / Counters: 170
• Current Load: 410 mA
• Communication Ports: 1 (SNP port hosted by the power supply module)
• Operating Temperature: 32°F to 140°F (0°C to 60°C)
• Bus Voltage: +5VDC
• Expandable: No external rack support
• Processor Type: 80188
• Current Load: 410 mA

For more detailed information, please check official datasheet. GE Fanuc Emerson IC693CPU311
