GE Fanuc IC693ALG390 Series 90-30 Input Module

GE Fanuc IC693ALG390 Series 90-30 Analog Output Module

This discontinued 2-channel voltage module delivers -10 to +10VDC outputs with ±5mV accuracy. Perfect for industrial control systems, instrumentation, and data loggers. Features factory calibration and configurable fail-safe operation.

Key Features

• Two isolated voltage channels (1500V RMS isolation)
• Hold last state or 0V output during CPU stop/reset
• LED power status indicator
• Shielded cable support for noise reduction

Technical Specifications

• Brand: GE Fanuc
• Model: IC693ALG390
• Output Range: -10 to +10VDC
• Resolution: 2.5mV
• Accuracy: ±5mV @25°C
• Channels: 2
• Update Rate: 5ms
• Operating Temp: 0-60°C (32-140°F)
• Power: 5VDC (32mA) + 24VDC (120mA)

Installation Guide

• Use shielded instrumentation cables
• Connect cable shields to GND terminal
• Set DEF0 jumper for fail-safe mode
• External power: 18-30VDC (±10% ripple)

Compatibility

Designed for Series 90-30 PLC systems. Backplane compatible.

Package Contents

• IC693ALG390 module with terminal block
• Installation documentation

Warranty & Shipping

• 12-month warranty
• Global shipping: FedEx, UPS, DHL

FAQ

• Q: Behavior during CPU shutdown?
  A: Configurable via DEF0 jumper (0V output or last-value hold)
• Q: External power required?
  A: 24VDC needed – use backplane or external supply
• Q: Supported cables?
  A: Shielded 18-22 AWG instrumentation cables
